Description
The Bose AMM112 multipurpose loudspeaker features a passive, coaxial two-way design with a 3-inch compression driver, 12-inch low-frequency transducer, and high output: 131 dB peak. Its proprietary Beamwidth Matching Waveguide ensures signature Bose sound quality, delivering consistent frequency response, clarity, and projection across the coverage area — a remarkably powerful audio experience for both performers and audiences.
Features
- Low-Frequency: 1 × 12 in (305 mm) woofer
- High-Frequency: 1 × 3 in (76 mm) compression driver
- Power Handling, long-term continuous: 300 W, passive; 300 W (low frequency) + 45 W (high frequency), bi-amp
- Frequency Range (-10 dB): 60 Hz – 20,000 Hz
- Coverage, Horizontal: 110°
- Compact high-output design delivers 131 dB peak output via coaxial driver: 3-inch compression driver, 12-inch low frequency driver with shared neodymium magnet
- Consistent tonality and voicing with AM array modules and AMU utility loudspeakers — easily create entire systems and save substantial time during system configuration
Why We Like This
A multipurpose cabinet is useful when the same loudspeaker needs to serve different positions in a venue.
FAQs
Q: What installation items are included?
A: The listed items are (1) installation guide; (1) AMM112.
Q: What mounting provisions does it have?
A: 2 × 35 mm (1.4 in) pole cup, 6 × M10 threaded inserts.
Based in Chicago, IL, Gear Club Direct supports musicians, integrators, and creators every day with reliable gear and expert service.
Tech Specs
Calculated Maximum SPL @ 1 m: |
121 dB continuous, 131 dB peak, both passive & bi-amp averaged |
Color: |
Black |
Coverage, Horizontal: |
110° |
Coverage, Vertical: |
60° |
Enclosure Material: |
Baltic birch plywood |
Frequency Range (-10 dB): |
60 Hz – 20,000 Hz |
Grille: |
Perforated steel, powder-coated finish |
High-Frequency: |
1 × 3 in (76 mm) compression driver |
Included Items: |
(1) installation guide; (1) AMM112 |
Ingress Protection: |
IP43 (front-of-house position only) |
Low-Frequency: |
1 × 12 in (305 mm) woofer |
Model: |
AMM112 Multipurpose Loudspeaker |
Power Handling, Peak: |
2800 W, passive; 2800 W (low frequency) + 720 W (high frequency), bi-amp |
Power Handling, long-term continuous: |
300 W, passive; 300 W (low frequency) + 45 W (high frequency), bi-amp |
Product Type: |
Installation loudspeaker |
Sensitivity (SPL/1 W at 1 m): |
96 dB, passive & bi-amp averaged |
Suspension/Mounting: |
2 × 35 mm (1.4 in) pole cup, 6 × M10 threaded inserts |
Unit of Sale: |
Each |
