Description
The Bose AMM108 multipurpose loudspeaker features a passive, coaxial two-way design with a 1.7-inch compression driver, 8-inch low-frequency transducer, and high output: 128 dB peak. Its proprietary Beamwidth Matching Waveguide ensures signature Bose sound quality, delivering consistent frequency response, clarity, and projection across the coverage area — a remarkably powerful audio experience for both performers and audiences.
Features
- Low-Frequency: 1 × 8 in (203 mm) woofer
- High-Frequency: 1 × 1.7 in (43 mm) compression driver
- Power Handling, long-term continuous: 150 W
- Frequency Range (-10 dB): 75 Hz – 20,000 Hz
- Coverage, Horizontal: 110°
- Compact high-output design delivers 128 dB peak via shared-magnet coaxial driver: 1.7-inch compression driver and 8-inch low-frequency driver
- Consistent tonality and voicing with AM array modules and AMU utility loudspeakers — easily create entire systems and save substantial time during system configuration
Why We Like This
A multipurpose cabinet is useful when the same loudspeaker needs to serve different positions in a venue.
FAQs
Q: What amplifier connection does it require?
A: The nominal impedance is 8 Ω, passive.
Q: What installation items are included?
A: The listed items are (1) installation guide; (1) AMM108.
Q: What mounting provisions does it have?
A: 1 × 35 mm (1.4 in) pole cup, 4 × M8 threaded inserts, 6 × M10 threaded inserts.
Based in Chicago, IL, Gear Club Direct supports musicians, integrators, and creators every day with reliable gear and expert service.
Tech Specs
Calculated Maximum SPL @ 1 m: |
116 dB continuous, 128 dB peak |
Color: |
Black |
Coverage, Horizontal: |
110° |
Coverage, Vertical: |
60° |
Enclosure Material: |
Baltic birch plywood |
Frequency Range (-10 dB): |
75 Hz – 20,000 Hz |
Grille: |
Perforated steel, powder-coated finish |
High-Frequency: |
1 × 1.7 in (43 mm) compression driver |
Included Items: |
(1) installation guide; (1) AMM108 |
Ingress Protection: |
IP43 (front-of-house position only) |
Low-Frequency: |
1 × 8 in (203 mm) woofer |
Model: |
AMM108 Multipurpose Loudspeaker |
Nominal Impedance: |
8 Ω, passive |
Power Handling, Peak: |
2400 W |
Power Handling, long-term continuous: |
150 W |
Product Type: |
Installation loudspeaker |
Sensitivity (SPL/1 W at 1 m): |
94 dB |
Suspension/Mounting: |
1 × 35 mm (1.4 in) pole cup, 4 × M8 threaded inserts, 6 × M10 threaded inserts |
Unit of Sale: |
Each |
