Description
Very linear frequency response characteristics, extreme high power handling while generating the lowest harmonic distortion of any comparable 18-inch transducer within its application range. The LF15X401 uses a fibre loaded cone assembly along with a high excursion triple roll surround. This combination provides remarkable strength and a peak to peak maximum excursion of 50 mm. The new dual forced hyper-venting system guarantee a very efficient voice coil ventilation for minimum power compression and incredible power handling.
Features
- 4-inch, fiberglass inside/outside copper voice coil
- 3000W continuous program power handling
- 96.5 dB Sensitivity
- 30 Hz – 1.5 kHz Frequency range
- Dual Forced Hyperventing System
- Dual spider design with silicon based dampening control
- Triple-roll surround and corrugated straight cone geometry
Why We Like This
It offers strong power handling with controlled excursion and efficient cooling for reliable bass performance.
FAQs
Q: What type of applications is this woofer suitable for?
It is designed for professional systems requiring controlled and powerful low-frequency output.
Q: How does it reduce power compression?
The dual forced hyper-venting system improves airflow and cooling.
Q: What is the frequency range?
30 Hz to 1.5 kHz.
Based in Chicago, IL, Gear Club Direct supports audio professionals with reliable components for high-performance sound systems.
Tech Specs
Nominal Diameter: |
15 inch / 381 mm |
Rated Impedance: |
8 ohm |
Program Power (watt): |
3000 W |
Power handling capacity: |
1500 W |
Sensitivity: |
96.5 dB |
Frequency range: |
30 - 1500 Hz |
Effective piston diameter: |
340 mm / 13.39 inch |
Max. Excursion Before Damage: |
50 mm / 1.97 inch |
Minimum Impedance (ohm): |
6.5 ohm |
Voice Coil Diameter: |
4.0 inch / 102 mm |
Voice Coil Winding Material: |
Copper |
Voice Coil Length: |
30 mm / 1.18 inch |
Number of layers: |
2 |
Kind of layers: |
inside/outside |
Top Plate Thickness: |
15 mm / 0.59 inch |
Cone Design: |
Straight |
Surround Design: |
Triple roll |
Dual-force air ventilation: |
Yes |
