Description
The StudioLive® 32S is a 40-channel digital mixer with one-to-one channel control and full-sized console power in a compact, rack-mountable design. AVB networking expands connectivity with EarMix 16M personal mixers and NSB-series stage boxes. It offers 16 FlexMixes configurable as auxes, subgroups, or matrix mixes, plus four effects buses, four subgroups, and 24 DCAs for flexible, intuitive routing and group control. Fat Channel processing delivers vintage EQ, classic compressors, and more on every input and output.
Equipped with a full 32 XMAX-R mic preamps and 16 Mix Outputs onboard, the StudioLive 32SX makes it easy to expand your system thanks to rock-solid audio networking. You can add remote I/O with NSB-Series stage boxes, personal monitor mixers with EarMix 16M, and even connect another StudioLive mixers for broadcast, monitor position, and more all with an Ethernet cable. Add 16 channels of Dante I/O with AVB-D16. No other system is as flexible.
The unique 64x64 bidirectional USB audio interface makes recording and routing plug-in racks effortless. Playback streams launch instantly with one button—no extra routing needed—for easy live monitoring. Included are PreSonus Capture® software and a perpetual Fender Studio Pro® Professional license. Record all 40 channels plus a stereo mix simultaneously via USB, SD Card, or both.
A free firmware update adds Milan certification, an improved limiter with variable release, and expanded Digital Reverb XL controls with new presets—offering enhanced power and precision. With this firmware update, you also get the 7 additional State Space Models EQs (10 total) and 8 analog-inspired compressors (11 total) from the Fat Channel Collection installed standard, adding even more processing to create studio-quality mixers for your live session.
Overview
Features
- Portable 40-channel digital mixer with dual-core FLEX DSP powering 286 processors
- 24 mix buses: 16 FlexMixes (aux, matrix, subgroup), 4 FX, 4 subgroups
- 32 XMAX-R fully recallable mic preamps and 16 mix outputs onboard
- 33 touch-sensitive, motorized faders for precise control
- Built-in 64x64 AVB networking for seamless StudioLive III, NSB, EarMix integration
- Industry-leading 128-channel USB audio interface
- Onboard multitrack SD recorder with true Virtual Soundcheck
- FLEX FX with 4 slots for classic reverb & delay
- Includes Capture Multitracking and Fender Studio Pro license for pro recording
- Optional Dante available with AVB-D16
Tech Specs
Type: |
Digital Mixer |
Channels: |
32 |
Inputs - Mic Preamps: |
16 x XLR (mic), 16 x XLR-1/4" combo (mic/line) |
Phantom Power: |
32 Channels |
Inputs - Line: |
1 x Dual RCA Stereo (tape), 4 x 1/4" (2 x stereo aux in) |
Outputs - Main: |
2 x XLR (main out), 1 x XLR (mono sum), 2 x 1/4" (monitor) |
Outputs - Other: |
12 x XLR (mix out), 4 x 1/4" (mix out), 1 x Dual RCA Stereo (tape), 4 x 1/4" (sub outs) |
Outputs - Digital: |
1 x XLR (AES/EBU) |
Busses/Groups: |
16 x FlexMix Buses (aux, subgroup, matrix), 26 total mix buses |
Talkback: |
1 x XLR (phantom power) |
Headphones: |
1 x 1/4" |
USB: |
1 x Type B (64 x 64) |
Computer Connectivity: |
USB 2.0 |
Bluetooth: |
v4.1 |
Faders: |
33 x Touch-sensitive motorized faders |
A/D Resolution: |
24-bit/48kHz |
24-bit/48kHz: |
FLEX FX Multi-effects processor, 4 x effects slots, 4 x effects buses |
Signal Processing: |
Fat Channel plug-ins, 10 x EQs, 10 x Compressors |
Features: |
Metro remote-control (UC 4.2) |
Transport: |
Yes |
DAW Control: |
Advanced Studio One, MCU Logic emulation, HUI Pro Tools emulation |
Screen: |
7" Touchscreen |
Storage: |
SD card recorder (34 track) |
Software: |
Fender Studio Pro |
Power Source:: |
Standard IEC AC cable |
