Description
The EAW MKC80 is a passive professional loudspeaker within EAW's MKC family for sound reinforcement and installed audio. It fits engineered systems where coverage, external amplification, and processing are selected for the venue.
Features
- Driver configuration: LF: 1 × 8 in cone, 2 in VC, Vented; HF: 1 × 1 in exit, 35 mm voice coil compression driver, Concentric Summation Array (CSA) loaded
- Operating range: 60 Hz–20 kHz
- Maximum SPL: 132 dB
- Nominal coverage: 90° H × 60° V (rotatable)
- Power handling: 450 W @ 8 Ω
- Operating mode: LF/HF; DSP with EAW Focusing and DynO
Why We Like This
The MKC80 suits systems that keep amplification and processing centralized while using a purpose-built EAW loudspeaker at the coverage point.
FAQs
Q: Do I need a separate amplifier for the MKC80?
A: Yes. The MKC80 is passive and needs external amplification. Match the amplifier and processing to EAW's guidance for the speaker.
Q: How do I connect the MKC80 to my amplifier?
A: The MKC80 connects through barrier strip; 2 × NL4. Check EAW's wiring and pinout information before making cables or terminations.
Q: Will the MKC80 cover my audience area?
A: That depends on the room, aiming, and seating geometry. Model the coverage before deciding speaker placement and quantity.
Q: What mounting hardware do I need for the MKC80?
A: Mounting options for the MKC80 include U-Bracket Ceiling mount bracket Metal wall mount bracket. Use EAW-approved hardware and have suspended installations designed by a qualified professional.
Based in Chicago, IL, Gear Club Direct supports musicians, integrators, and creators every day with reliable gear and expert service.
Tech Specs
Audio Connections: |
Barrier strip; 2 × NL4 |
Driver Configuration: |
LF: 1 × 8 in cone, 2 in VC, Vented; HF: 1 × 1 in exit, 35 mm voice coil compression driver, Concentric Summation Array (CSA) loaded |
EAW Technologies: |
EAW Focusing, DynO, Symmetry of Sources, Concentric Summation Array (CSA), Beamwidth Matched Crossovers |
Finish: |
White |
Input Impedance: |
8 Ω |
Maximum SPL: |
132 dB |
Nominal Coverage: |
90° H × 60° V (rotatable) |
Power Handling: |
450 W @ 8 Ω |
Product Height: |
16.6 in |
Product Length: |
10.5 in |
Product Type: |
Passive Loudspeaker |
Product Width: |
10.0 in |
Recommended High-Pass Filter: |
60 Hz 12 dB/oct |
Rigging / Mounting: |
U-Bracket Ceiling mount bracket Metal wall mount bracket |
