Description
The EAW AC6 is a self-powered column loudspeaker within EAW's Adaptive family for professional installed and production sound. It fits projects where controlled coverage and a narrow enclosure profile are useful.
Features
- Driver configuration: LF: 6 × 6 in cone, 1.7 in voice coil vented (with CSA); HF: 30 × 19 mm dome tweeter, horn loaded
- Operating range: 65 Hz–20 kHz
- Maximum SPL: 143 dB (peak at 1 m, unadapted)
- Nominal coverage: 120° H × adaptive V
- Integrated amplification: 600 W peak
- Operating mode: Self-powered; DSP with EAW Focusing and Adaptive Performance
Why We Like This
The AC6 combines a narrow architectural profile with the system-control features expected in professional installations.
FAQs
Q: Do I need a separate amplifier for the AC6?
A: No. Amplification is built into the AC6. Plan for the correct AC power and signal connections before using it.
Q: Will the AC6 work on different mains voltages?
A: Yes. The AC6 accepts 100–240 V AC. Check the AC connector and local power requirements before use.
Q: Does the AC6 support Dante?
A: Yes. The AC6 supports Dante network audio. Plan the network switch, cabling, and audio routing as part of the system design.
Q: Will the AC6 work for my room?
A: That depends on the audience area, mounting height, and aiming. Model the coverage and placement before deciding how many columns are needed.
Based in Chicago, IL, Gear Club Direct supports musicians, integrators, and creators every day with reliable gear and expert service.
Tech Specs
AC Connector: |
Neutrik powerCON TRUE1 TOP |
AC Frequency: |
50 Hz to 60 Hz |
AC Voltage: |
100–240 V |
Amplifier Output: |
600 W peak |
Amplifier Type: |
Class D |
Audio Connections: |
XLR input with loop-through; AES digital audio; Dante network audio; etherCON/RJ-45 network |
Driver Configuration: |
LF: 6 × 6 in cone, 1.7 in voice coil vented (with CSA); HF: 30 × 19 mm dome tweeter, horn loaded |
EAW Technologies: |
EAW Focusing, DynO, Adaptive Performance, Concentric Summation Array (CSA), Beamwidth Matched Crossovers |
Enclosure Material: |
Aluminum Housing with Stainless Steel |
Finish: |
Black |
Maximum SPL: |
143 dB (peak at 1 m, unadapted) |
Nominal Coverage: |
120° H × adaptive V |
Power Consumption: |
600 W |
Product Height: |
38.7 in |
Product Length: |
10.4 in |
Product Type: |
Powered Column Loudspeaker |
Product Width: |
9.4 in |
