Description

The award-winning Veritas series from Bose delivers superior background/foreground music, paging and multimedia for commercial applications. Bluetooth 5.0 wireless input and user-intuitive OLED screen with quick-start QR code simplify setup—whether you’re a pro installer or a DIYer.

Features

Rated Power, Symmetrical: 2 x 160 W at 70/100V
Premium amplification with advanced DSP for optimized performance
Bluetooth connectivity and RCA connectivity—no wire splicing required

Why We Like This

Automatic music-to-page handling is useful in a business where staff need to make announcements without working through mixer settings.

FAQs

Q: What installation items are included?
A: The listed items are (4) mounting feet with pins; (2) 5-pin Euroblock connectors; (1) 4-pin Euroblock connector; (3) 2-pin Euroblock connectors; (1) power cord; (1) installation guide.

Q: What mains power does it accept?
A: The specified mains range is 100–240 VAC (±10%), 50/60 Hz.

Q: How much amplifier power is available?
A: The rated output is 2 x 160 W at 70/100V.

Based in Chicago, IL, Gear Club Direct supports musicians, integrators, and creators every day with reliable gear and expert service.

Tech Specs

A/D and D/A Converters:	48 kHz / 24-bit
AC Power Consumption:	13.6 W standby, 500 W maximum
Adjustment Range:	0 dB to -30 dB (line), 0 dB to +50 dB (page)
Audio Inputs, Analog — Connectors:	(2) RCA stereo pairs, (2) 5-pin Euroblock, (1) 4-pin Euroblock
Audio Inputs, Analog — Input Channels:	(2) balanced line, (2) unbalanced line, (1) balanced mic/line
Audio Inputs, Analog — Nominal Input Level:	4 dBu (line), -38 dBu (page)
Audio Inputs, Analog — Sensitivity:	-8 dBu (line), -58 dBV (page)
Audio Latency:	10.4 ms (any input to speaker output or aux output)
Audio Outputs, Analog — Channels:	(2) loudspeaker, (1) unbalanced line
Audio Outputs, Analog — Connectors:	(2) 2-pin inverted Euroblock, (1) RCA stereo pair
Audio Outputs, Analog — Nominal Output Level:	2 × 160 W at 70V/100V (loudspeaker), 2 dBu (auxiliary)
Channel Separation (Crosstalk):	≤ -58 dBu below rated power, 1 kHz
Controls, Front Panel:	Power on/off switch, input select switch (A/Bluetooth/B), rotary encoder
Controls, Rear Panel:	Amplifier mode DIP switches, input gain knobs (A, B, page), page threshold knob, mute connector, ControlCenter ports
Cooling System:	Fan system, left-to-right airflow
Dynamic Range:	88 dB
Frequency Response:	20 Hz – 20 kHz (+0/-3 dB) at 1 W, 1 kHz reference
Included Items:	(4) mounting feet with pins; (2) 5-pin Euroblock connectors; (1) 4-pin Euroblock connector; (3) 2-pin Euroblock connectors; (1) power cord; (1) installation guide
Input Impedance:	20 kΩ (line), 2 kΩ (page)
Input Range:	-8 dBu to +22 dBu (line), -58 dBu to +12 dBu (page)
Mains Connector:	IEC C14 inlet
Mains Voltage:	100–240 VAC (±10%), 50/60 Hz
Maximum Input Level:	22 dBu (line), 12 dBu (page)
Model:	Veritas 2160BH 120V US
Presets:	70 Hz high-pass filter, 80 Hz high-pass filter, AMU105, AMU108, DesignMax (all models), EdgeMax (all models), FreeSpace FS (all models), subwoofer
Processing Functions:	Loudspeaker EQ, Opti-Voice paging, Dynamic EQ
Product Type:	Installation amplifier
Protections:	High temperature, output short circuit, excessively low/high AC line voltage
Rated Power, Symmetrical:	2 x 160 W at 70/100V
THD+N:	≤ 0.5% at rated power
Unit of Sale:	Each
