Description
Ideal for zone-expansion applications, Bose PowerSpace amplifiers enhance any premium commercial sound installation with clean, reliable power — and digital connectivity. A Bose AmpLink input allows for multiple channels of uncompressed, low-latency digital audio from Bose DSPs via a single Cat 5 cable.
Features
- Rated Power, Symmetrical: 600 W
- 600 watts per channel and works seamlessly with loudspeakers, DSPs, and controls to create complete commercial sound systems
- AmpLink input for simplified multichannel digital audio connection to compatible DSPs, reducing terminations and related points of failure
Why We Like This
Digital audio input gives an installer a practical way to extend a compatible system into additional amplifier channels.
FAQs
Q: What installation items are included?
A: The listed items are (1) 2-pin Euroblock connector; (1) Cat 5e cable, 3.3 ft (1 m); (2) 3-pin Euroblock connectors; (1) I-Share jumper; (5) terminal forks, 14–16 AWG; (1) PowerSpace P2600A; (1) installation guide; (1) IEC power cord.
Q: What mains power does it accept?
A: The specified mains range is 100–240 VAC (±10%), 50/60 Hz.
Q: What mounting provisions does it have?
A: Rack-mounting.
Based in Chicago, IL, Gear Club Direct supports musicians, integrators, and creators every day with reliable gear and expert service.
Tech Specs
AC Power Consumption: |
25 W auto-standby, 570 W maximum |
Audio Inputs, Analog — Connectors: |
(1) 6-pin Euroblock |
Audio Inputs, Analog — Input Channels: |
2 balanced |
Audio Inputs, Analog — Sensitivity: |
-10 dBV, 4 dBu, 14 dBu |
Audio Inputs/Outputs, Digital — Channels: |
8 AmpLink in, 8 AmpLink thru |
Audio Inputs/Outputs, Digital — Connectors: |
(1) RJ-45 AmpLink in / (1) RJ-45 AmpLink thru |
Audio Outputs, Analog — Channels: |
2 |
Audio Outputs, Analog — Connectors: |
(1) 4-terminal block |
Channel Separation (Crosstalk): |
> 80 dB at 1 kHz, > 65 dB at 20 kHz |
Controls, Front Panel: |
(1) power button |
Controls, Rear Panel: |
Mute, output attenuators, DIP switches for amplifier configuration, input selector, update port, gain/sensitivity |
Cooling System: |
Microprocessor-controlled variable-speed fans, front-to-back air flow |
DSP-Enabled: |
No |
Dynamic Range: |
≥ 100 dB at rated power, A-weighted |
Frequency Response: |
20 Hz – 20 kHz (±1 dB) at 1 W, 4–8 Ω / 20 Hz – 20 kHz (±1 dB) at 1 W with 50 Hz high-pass filter, 70/100V |
Gain, High-Impedance: |
35 dB, 70V mode / 38 dB, 100V mode |
Gain, Low-Impedance: |
35 dB |
Included Items: |
(1) 2-pin Euroblock connector; (1) Cat 5e cable, 3.3 ft (1 m); (2) 3-pin Euroblock connectors; (1) I-Share jumper; (5) terminal forks, 14–16 AWG; (1) PowerSpace P2600A; (1) installation guide; (1) IEC power cord |
Input Impedance: |
10 kΩ |
LED Status Indicators: |
(1) power/status LED, (4) input signal LEDs, (4) output limit LEDs |
Mains Connector: |
IEC 60320-C14 inlet |
Mains Voltage: |
100–240 VAC (±10%), 50/60 Hz |
Maximum Input Level: |
22 dBu at 14 dBu sensitivity |
Maximum Peak Power, Symmetrical: |
1200 W |
Model: |
PowerSpace P2600A 120V NA |
Number of Channels: |
2 |
Power Class: |
Class D |
Product Type: |
Installation amplifier |
Rack Spaces: |
1 |
Rated Power, Symmetrical: |
600 W |
Suspension/Mounting: |
Rack-mounting |
THD+N: |
< 0.04% at 1 kHz, 4–8 Ω, 70V/100V |
Type: |
6-pin Euroblock |
Unit of Sale: |
Each |
