Description
The Bi-amped 3-way full range MC15-R is a compact 15" 990-Watt asymmetrical close cluster array element that is ideally suited to a broad range of speech and music sound reinforcement applications in fixed installation, portable and touring audio systems. The MC15-R is designed to work in conjunction with Lake DSP and Lab Gruppen amplification, providing optimal FOH performance, as well as offering considerable flexibility to readily adapt to varying venue requirements.
Features
-
15" Point Source Close Cluster Array Element for Install and Touring
-
High power 15" low frequency transducer with lightweight neodymium motor
-
1 x 1.4" exit coaxial neodymium mid-high compression driver
-
Integral Asymmetrical Dendritic waveguide for advanced dispersion characteristics
-
990 Watts continuous, 3,960 Watts peak power
-
30° horizontal x 0 - 30° asymetrical vertical dispersion
-
I-Bar & Track suspension system with advanced ergonomic design for rapid deployment and ease of use
-
Seamless integration with Lab Gruppen amplifiers and Lake DSP for a complete system solution
-
Advanced linear phase FIR hybrid processing for exceptional sound quality
-
IP54 dust and water ingress protection
-
Weather-resistant enclosure construction with durable semi matte black PU paint finish
-
Tour grade, NL4M connectors for input and link connection
Specification
System
| Frequency response (-3 dB)1 |
55 Hz - 20 kHz |
| Frequency response (-10 dB)1 |
42 Hz - 20 kHz |
| Nominal dispersion @ -6 dB points |
30 degrees (H) x 0/-30 degrees (V) |
| Power handling ((IEC) PASSIVE) |
LF: 800 W continuous, 3200 W peak MHF: 190 W continuous, 380 W peak Combined: 990 W continuous, 3960 W peak |
| Sensitivity |
LF: 102 dB (1 W @ 1 m) ² MHF: 114.5 dB (1 W @ 1 m) ² |
| Maximum SPL (FR) |
144 dB ³ |
| Impedance |
LF: 8 Ω MHF: 12 Ω |
| Crossover type |
External bi-amp |
| Components |
1 x 15" (380 mm) LF driver 1 x 1.4" (35 mm) exit, large format dual compression driver |
| IP Rating |
IP54 |
| UV Rating |
4-5 (ASTM G155) |
Enclosure
| Connectors |
2 x NL4M |
| Wiring |
Bi-amp mode: Pins 1+ / 1- LF, pins 2+ / 2- MHF |
| Dimensions H x W x D |
700 x 522 x 648 mm (27.6 x 24 x 18.1") |
| Net weight |
47.2 kg (104.05 lbs) |
| Construction |
12 mm and 15 mm (1/2" and 5/8") plywood |
| Finish |
Black textured PU paint |
| Grille |
Powder coated perforated steel |
| Flying hardware |
Rail and track custom |
