Description

The TASCAM SS-R300N is a two-channel SD/USB audio recorder and player for installed sound, broadcast facilities, halls and conference systems. Network file transfers and external control support integration into managed AV systems.

Features

SD card and USB flash-drive recording and playback up to 96 kHz/24-bit
Two SD card slots and a USB media port
Ethernet, RS-232C serial and parallel external control
Balanced analog and AES/EBU digital input/output
Q-SYS plugin support
Offline playlist and event-list editing with TASCAM Playlist Editor
Assignable front-panel USER buttons

Why We Like This

Secure network file exchange lets staff manage recordings without physically removing media from an equipment rack.

FAQs

Q: Is Dante included in the base recorder?
A: No. Dante compatibility requires the optional IF-DA2 interface card to be installed.

Q: Can it play audio CDs?
A: Yes, when connected to a compatible third-party external USB CD drive. An internal CD drive is not part of the base unit.

Q: Which media capacities are supported?
A: TASCAM lists SD cards from 512 MB to 2 GB, SDHC from 4 GB to 32 GB, SDXC from 64 GB to 512 GB, and USB flash drives from 512 MB to 512 GB. Media must use FAT16, FAT32 or exFAT.

Based in Chicago, IL, Gear Club Direct supports musicians, integrators, and creators every day with reliable gear and expert service.

Tech Specs

Analog audio input and output / ANALOG INPUTS (BALANCED) - Connecter:	XLR-3-31 equivalent (1: GND, 2: HOT, 3: COLD)
Analog audio input and output / ANALOG INPUTS (BALANCED) - Input impedance:	10kΩ or higher
Analog audio input and output / ANALOG INPUTS (BALANCED) - Maximum input level(switchable):	+15dBu (Ref. Level: -9dBFS) / +18dBu (Ref. Level: -14dBFS) / +20dBu (Ref. Level: -16dBFS) / +22dBu (Ref. Level: -18dBFS) / +24dBu (Ref. Level: -20dBFS)
Analog audio input and output / ANALOG INPUTS (BALANCED) - Nominal input level:	+4dBu (Ref. Level: other than -9dBFS) / +6dBu (Ref. Level: -9dBFS)
Analog audio input and output / ANALOG INPUTS (UNBALANCED) - Connecter:	RCA pin jacks
Analog audio input and output / ANALOG INPUTS (UNBALANCED) - Input impedance:	10kΩ or higher
Analog audio input and output / ANALOG INPUTS (UNBALANCED) - Maximum input level:	+6dBV
Analog audio input and output / ANALOG INPUTS (UNBALANCED) - Nominal input level:	-10dBV
Analog audio input and output / ANALOG OUTPUTS (BALANCED) - Connecter:	XLR-3-32 equivalent (1: GND, 2: HOT, 3: COLD)
Analog audio input and output / ANALOG OUTPUTS (BALANCED) - Maximum output level (switchable):	+15dBu (Ref. Level: -9dBFS) / +18dBu (Ref. Level: -14dBFS) / +20dBu (Ref. Level: -16dBFS) / +22dBu (Ref. Level: -18dBFS) / +24dBu (Ref. Level: -20dBFS)
Analog audio input and output / ANALOG OUTPUTS (BALANCED) - Nominal output level:	+4dBu (Ref. Level: other than -9dBFS) / +6dBu (Ref. Level: -9dBFS)
Analog audio input and output / ANALOG OUTPUTS (BALANCED) - Output impedance:	100Ω
Analog audio input and output / ANALOG OUTPUTS (UNBALANCED) - Connecter:	RCA pin jacks
Analog audio input and output / ANALOG OUTPUTS (UNBALANCED) - Maximum output level:	+6dBV
Analog audio input and output / ANALOG OUTPUTS (UNBALANCED) - Nominal output level:	-10dBV
Analog audio input and output / ANALOG OUTPUTS (UNBALANCED) - Output impedance:	200Ω
Analog audio input and output / PHONES - Connecter:	φ6.3mm (1/4") standard stereo jack
Analog audio input and output / PHONES - Maximum output level:	45mW + 45mW or higher (THD+N 0.1% or less, into 32 Ω loads) Note) 0 dBV=1 Vrms, 0 dBu=0.775 Vrms
Control input/output ratings - Infrared receiver:	for RC-10 (Wireless remote control)
Control input/output ratings / CD DRIVE - Connecter:	USB type-C (screw lock supported)
Control input/output ratings / CD DRIVE - Operation mode:	Host
Control input/output ratings / CD DRIVE - Power supply capacity:	DC 5V max. 1.5A (USB Type-C 1.5A current conforming)
Control input/output ratings / CD DRIVE - Protocol:	USB 2.0 High-Speed (480Mbps)
Control input/output ratings / ETHERNET - Connecter:	RJ45
Control input/output ratings / ETHERNET - Standard:	100BASE-TX
Control input/output ratings / ETHERNET - Supported Application Protocols:	・Telnet ・OSC (Open Sound Control) ・SNTP client ・FTP server ・FTP Client ・SFTP (SSH FTP) server ・SFTP (SSH FTP) client ・FTPS (FTP over SSL/TLS) client (Explicit mode, TLSv1.2/1.3)
Control input/output ratings / PARALLEL - +5 V power supply maximum supplied current:	100mA
Control input/output ratings / PARALLEL - Connecter:	D-sub 9-pin (female, inch-standard)
Control input/output ratings / PARALLEL - High level minimum input voltage:	+2.31V
Control input/output ratings / PARALLEL - Low level maximum input voltage:	+0.99V
Control input/output ratings / PARALLEL - Low level maximum output voltage:	0.5V
Control input/output ratings / PARALLEL - Maximum input voltage:	+5.5V
Control input/output ratings / PARALLEL - Output format:	Open collector (10 Ω output impedance, 20 V withstand voltage, 35 mA maximum)
Control input/output ratings / REMOTE - Connecter:	φ2.5mm (3/32") TRS jack (for TASCAM RC-3F or RC-20 (sold separately))
Control input/output ratings / RS-232C - Connecter:	D-sub 9-pin (female, inch-standard)
Control input/output ratings / USB - Connecter:	USB type-A 4-pin
Control input/output ratings / USB - Operation mode:	Host
Control input/output ratings / USB - Power supply capacity:	DC 5V max. 0.5A
Control input/output ratings / USB - Protocol:	USB2.0 High-Speed (480Mbps)
Digital audio input/output / DIGITAL INPUT (AES/EBU) - Connecter:	XLR-3-31 equivalent
Digital audio input/output / DIGITAL INPUT (AES/EBU) - Format:	AES3-2003/IEC60958-4 (AES/EBU)
Digital audio input/output / DIGITAL INPUT (AES/EBU) - Input impedance:	110Ω
Digital audio input/output / DIGITAL INPUT (AES/EBU) - Input signal voltage amplitude:	0.2 - 7.0 Vp-p
Digital audio input/output / DIGITAL INPUT (AES/EBU) - Sampling frequencies:	44.1k / 48k / 96k Hz (SRC ON: 32kHz - 192kHz)
Digital audio input/output / DIGITAL INPUT (S/PDIF) - Connecter:	RCA pin jacks
Digital audio input/output / DIGITAL INPUT (S/PDIF) - Format:	IEC60958-3
Digital audio input/output / DIGITAL INPUT (S/PDIF) - Input impedance:	75 Ω
Digital audio input/output / DIGITAL INPUT (S/PDIF) - Input signal voltage amplitude:	0.2 - 0.6 Vp-p
Digital audio input/output / DIGITAL INPUT (S/PDIF) - Sampling frequencies:	44.1k / 48k / 96k Hz (SRC ON: 32kHz - 192kHz)
Digital audio input/output / DIGITAL OUTPUT (AES/EBU) - Connecter:	XLR-3-32 equivalent
Digital audio input/output / DIGITAL OUTPUT (AES/EBU) - Format:	AES3-2003/IEC60958-4 (AES/EBU)
Digital audio input/output / DIGITAL OUTPUT (AES/EBU) - Output impedance:	110Ω
Digital audio input/output / DIGITAL OUTPUT (AES/EBU) - Output voltage:	2.0 - 7.0 Vp-p
Digital audio input/output / DIGITAL OUTPUT (AES/EBU) - Sampling frequencies:	44.1k / 48k / 96k Hz
Digital audio input/output / DIGITAL OUTPUT (S/PDIF) - Connecter:	RCA pin jacks
Digital audio input/output / DIGITAL OUTPUT (S/PDIF) - Format:	IEC60958-3
Digital audio input/output / DIGITAL OUTPUT (S/PDIF) - Output impedance:	75Ω
Digital audio input/output / DIGITAL OUTPUT (S/PDIF) - Output voltage:	0.5 +/-0.1 Vp-p
Frequency Response - 20 Hz - 20 kHz:	+/-0.5 dB (LINE IN to LINE OUT, Fs 44.1/48 kHz, JEITA)
Frequency Response - 20 Hz - 40 kHz:	+0.5/-3 dB (LINE IN to LINE OUT, Fs 96 kHz, JEITA)
Manufacturer:	TASCAM
Model:	SS-R300N
Playback file formats - AAC:	44.1k / 48k Hz, 32kbps - 320kbps, VBR (MPEG Extended HE-AAC (Audio stream), DRM not supported)
Playback file formats - CD-DA:	44.1kHz, 16bit (When using an external CD drive)
Playback file formats - MP3:	44.1k / 48kHz, 64k / 128k / 192k / 256k / 320k bps
Playback file formats - WAV:	44.1k / 48k / 96k Hz, 16 / 24bit
Product Type:	Network SD/USB audio recorder and player
Recording file formats - MP3:	44.1k / 48kHz, 64k / 128k / 192k /256k / 320k bps
Recording file formats - WAV:	44.1k / 48k / 96k Hz, 16 / 24bit
Specifications - Crosstalk between channels:	100 dB or more (LINE IN to LINE OUT, Fs = 44.1/48/96 kHz, JEITA)
Specifications - Distortion:	0.002% or less: (LINE IN to LINE OUT, Ref. Level: -16 dBFS, Fs = 44.1/48/96 kHz, JEITA)
Specifications - Dynamic range:	106 dB or more (LINE IN to LINE OUT, Fs = 44.1/48/96 kHz, JEITA)
Specifications - Media:	2 SD card slots, 1 USB port, SD cards (512 MB - 2 GB), SDHC cards (4 GB - 32 GB), SDXC cards (64 GB - 512 GB), USB flash drives (512 MB - 512 GB) Note) Media must be formatted as FAT16, FAT32 or exFAT.
Specifications - Number of channels:	2 channels (Stereo) / 1 channel (Monaural)
Specifications - Operating Humidity:	25 - 85% RH (non-condensing at 32°C)
Specifications - Operating temperature range:	5 - 35 °C
Specifications - Power:	AC 100-240V, 50/60Hz
Specifications - Power consumption:	When using RC-SS150, IF-DA2: 29 W When power is off (when in standby mode): 0.4 W Note) Time until switching to standby mode: 20 min (Europe only)
Specifications - S/N ratio:	106 dB or more (LINE IN to LINE OUT, Fs = 44.1/48/96 kHz, JEITA)
