Description
The L2406-T is a full range high intelligibility compact 3 way column speaker array with vertical controlled directivity for medium to large size installations. It is equipped with six 5" woofers and four 1" dome tweeters mounted in front of the two central woofers. This particular design permits coherent sound dispersion minimizing lobing in a very compact enclosure. The two central woofers are controlled differently from the other four because of the tweeters in front of them, in order to improve the directivity providing a true cardioid column operation.The wide coverage horizontal angle and the controlled vertical dispersion allow correct sound reproduction serving a wide area and assistance in limiting feedback and reverberated sound. A speech filter can be activated for enhancing the voice frequencies and improving speech intelligibility. The crossover is designed to avoid secondary lobing creation. Mounting accessories are provided and are designed to keep the column as close as possible to the wall and simplify the installation allowing suitable tilting. The L2406-T can be used connected to a low impedance amplifier to handle 200 W RMS power. It also includes a 60 W line transformer for 100 V systems. The crossover is equipped with a circuit to protect the four 1" dome tweeters.
Features
- 200 W RMS power handling
- 126 dB max SPL
- 100 ÷ 20000 Hz frequency range
- 150° x 30° constant directivity coverage angle
- 6 x 5" woofers
- 4 x 1" dome tweeters
- Baltic birch plywood cabinet
- Speech enhancer filter
- Built-in wall mounting accessories
Why We Like This
The controlled directivity and speech optimization make it a powerful solution for environments where clarity and coverage are critical.
FAQs
Q: Is this speaker suitable for speech-focused environments?
Yes. It includes a speech enhancer filter and controlled dispersion for high intelligibility.
Q: Can it be used in 100V systems?
Yes. It includes a built-in 60W transformer for 100V line operation.
Q: Is mounting hardware included?
Yes. It includes wall mounting accessories with tilt adjustment.
Based in Chicago, IL, Gear Club Direct supports installers and audio professionals with reliable gear and expert service you can trust.
Tech Specs
Frequency Response (-10dB): |
100 Hz - 20000 Hz |
Max SPL @ 1m: |
126 dB |
Horizontal coverage angle: |
150° |
Vertical coverage angle: |
30° |
Directivity index Q: |
9 |
System Sensitivity: |
97 dB |
Amplification: |
Full Range |
Protections: |
Dynamic active mosfet |
Crossover Frequencies: |
2000 Hz |
Dimensions: |
32.52" x 5.31" x 5.51" |
Weight: |
28.22 |
