RCF F12-XR 12 Channel Mixer w/ FX and Recording

Description
Delivery & Returns
Customer Reviews

Description

The RCF F-12XR is a mixer designed for live sound applications. It has 6 mic preamps, 4 mono line inputs, and four stereo line inputs. Line connections can be made over 1/4" connections or RCA terminations. You'll find 3-band EQs on the mono channels, and 2-band EQs on the stereo line inputs. Single-knob compressors are available on channels 1 through 4, and phantom power is available on all microphone inputs.

24-bit effects are on hand to give you reverb, echo, delay, flanger, and more. Route to main outputs, monitors, or headphones, thanks to the comprehensive output section. With the USB output, you can record stereo audio on Mac, Windows, or iOS devices (with compatible adapters).

High-Quality Preamps

High-quality preamplifiers with phantom power, inspired by the E-Series mixers, offer high-quality sound and dynamics. Line-level signals are less noisy when connected using the separate line input jack sockets.

EQ on Mono & Stereo Channels

The F-12XR features 3-band EQ on the mono channels, and 2-band EQ on stereo channels for transparent sound shaping.

Single-Knob Compressors

The F-Series compressor offers transparent limiting for the dynamic range of instruments and voices.

24-Bit FX

RCF has selected 16 studio-quality effects designed for everyday use when you need great quality FX processing without the need of an external FX unit. You'll find Reverbs (halls, rooms, plates, spring), Delays (mono, stereo, and multi-tap), Chorus, Flanger, and Echo.

USB Recording and Playback

Record directly to your computer. No need for external interfaces or multiple connections and levels to check. Just plug in a USB lead to a PC or to your iPhone / iPad (2 or later) using Apple's Camera Connection Kit / Lightning-to-USB Camera Adapter. Select the USB routing and you'll have CD-quality recording and stereo playback, effortlessly. The class-compliant design allows recording and playback from Windows, MacOs, and iOS (through USB adapter) without any additional software.

RCF F12-XR Specs

Inputs

Input Connections	6 x XLR Inputs 12 x 1/4" Inputs (4 x Stereo Pairs, 4 Mono) 4 x RCA Inputs (2 x Stereo Pair) 1 x 1/4" Footswitch Input
Gain Range	0 to -50 dB
Input Impedance	Mic: 14 Kilohms Line: 21 Kilohms Stereo Line: 15 Kilohms
Frequency Response	20 Hz to 20 kHz
Gain Selection	20 dB to -30 dB
Low Cut Filters	80 Hz
Phantom Power	+48 V

Outputs

Output Connections	2 x XLR Main Outputs 2 x 1/4" Main Outputs 2 x 1/4" CTL Room Outputs 2 x 1/4" Auxiliary Outputs 1 x 1/4" Headphones Output
Output Level	28 dBu
Headphone Impedance	150 Ohms

System Specifications

Compressor	Single-Control Compressors on Channels 1 through 4
Equalization	Input Channels: 2 Shelving / 1 Generic High: ±15 dB at 10 kHz, Shelving Mid: ±15 dB at 1250 Hz, Bell Low: ±15 dB at 100 Hz, Shelving
USB Audio	Type-B, 2-Channel I/O, 44.1 or 48 kHz Sample Rate
Case Material	Metal
Frequency Response	20 Hz to 20 kHz
THD+N	< 0.02% (20 dB Gain, 0 dBu Out, A-Weighted)
Voltage Requirements	100 to 240 VAC
Power Consumption	24 W
Power Supply	Internal
Dimensions (D x H x W)	14 x 3.8 x 14.7" / 35.5 x 9.7 x 37.3 cm
Weight	9.9 lb / 4.5 kg
