Description
EVOX J11 is an active, three-way portable column system designed for maximum clarity and power in a compact format. A 1.75” compression driver coupled with a 120° × 40° True Resistive Waveguide ensures wide, consistent coverage, while 12 x 3” full-range transducers and a high-power 12” woofer in a bass-reflex enclosure deliver articulate mids and deep, controlled lows. Driven by a 3500W onboard dual-channel Class-D amplifier, EVOX J11 delivers an impressive 132 dB Max SPL output. Part of the EVOX J Series, it incorporates RCF’s tour-grade technology into a sleek, unobtrusive package that delivers crystal-clear vocals, natural musical response, and effortless deployment for bands, DJs, and live performers.
Features
- 132 dB Max SPL
- 3500 W Class-D Amplifier - Built-In DSP
- 1.75” Neo Compression Driver - 120° X 40° True Resistive Waveguide
- 12 × 3” Full-Range Neo Transducers
- 12” High-Power Woofer
- Enhanced Coverage And Clarity
- Composite Cabinet With Aluminum Stand Mount
- Sleek, Road-Ready Design
- Top Speaker Padded Carrying Bag Included
Why We Like This
- Delivers high output in a compact column system
- Provides consistent coverage with minimal setup components
- Designed for portable use with built-in amplification and DSP
FAQs
Q: Is the EVOX J11 an active speaker system?
A: Yes, it includes built-in Class-D amplification and DSP.
Q: What power connection does the system use?
A: It uses Powercon TRUE1 TOP IN/OUT connectors.
Q: Is a carrying accessory included?
A: Yes, a padded carrying bag for the column array is included.
Based in Chicago, IL, Gear Club Direct supports musicians, DJs, and creators every day.
Tech Specs
Frequency Response: |
37 Hz - 20000 Hz |
Max SPL @ 1m: |
132 dB |
Horizontal coverage angle: |
120° |
Vertical coverage angle: |
40° |
Compression Driver: |
1 x 0.75'' neo, 1.75'' v.c |
Fullrange: |
12 x 3.0'' neo, 1.0'' v.c |
Woofer: |
1 x 12'', 2.5'' v.c |
Input signal: |
bal/unbal |
Input connectors: |
Combo XLR/Jack |
Output connectors: |
XLR |
Input sensitivity: |
+4 dBu |
Crossover Frequencies: |
160 Hz/1800 Hz |
Protections: |
Thermal, RMS |
Limiter: |
Soft Limiter |
Controls: |
Volume, Presets: LINEAR/LIVE, CLUB, VOICE |
Total Power: |
3500 W Peak |
High frequencies: |
1500 W Peak |
Low frequencies: |
2000 W Peak |
Cooling: |
Convection |
Connections: |
Powercon TRUE1 TOP IN/OUT |
Safety agency: |
CE compliant |
Cabinet/Case Material: |
PP Composite |
Handles: |
1 Top |
Pole mount/Cap: |
Quick-fit socket |
Grille: |
Steel |
Color: |
Black, White - RAL 9003 |
Dimensions: |
81.89" x 13.78" x 18.23" |
Weight: |
63.93 lbs |
Shipping Dimensions: |
26.61" x 17.76" x 22.87" |
