Description
KPS 164D is a professional 4-channel amplifier with a total output power of 640 W, designed for high-demanding audio installations where flexibility, reliability, and advanced control are essential. Equipped with Class-D amplification and integrated DSP, it provides complete and accurate signal processing, with intuitive configuration through RCF's RDSpace software. The library of RCF loudspeakers’ presets simplifies the setup and ensures optimal performance. Native Ethernet connectivity makes it ideal for distributed systems with independent zone control, while the integrated wireless access point allows direct connection with mobile devices. Equipped with Audinate Dante™ AoIP networks interface, allowing the distribution of 4 digital audio channels.
Features
- 4 x 160 W Class-D power amplifier
- Integrated signal processing
- Presets for RCF loudspeakers
- Low and high impedance outputs configuration
- Flexible and scalable multi-zone architecture
- Network management with RDSpace software
- API drivers for third party control systems
- PoE wall accessories for remote control
- Powershare across each channels pair up to 320 W
- Audinate Dante™ networks interface (4 channels)
Why We Like This
It combines four channels of DSP-controlled amplification with Dante networking—perfect for scalable, cable-efficient audio systems.
FAQs
Q: What is Dante used for?
It allows digital audio to be routed over Ethernet, simplifying system wiring.
Q: Can this run multiple zones?
Yes. It has four independent channels for multi-zone control.
Q: Does it support 70/100V systems?
Yes. It supports both low and high impedance configurations.
Based in Chicago, IL, Gear Club Direct supports advanced audio installations with network-ready and scalable solutions.
Tech Specs
Amplifier Class: |
D |
Output Power: |
4 x 160 W @ 4 ohm 4 x 160 W @ 8 ohm 2 x 320 W @ 4 ohm (bridge) 2 x 320 W @ 8 ohm (bridge) |
Output power @ 100 V: |
2 x 320 W @ 100 V |
Output power @ 70 V: |
2 x 320 W @ 70 V |
Frequency Response (-3dB): |
20 Hz - 20000 Hz |
SNR Analog inputs (“A” weighted): |
>106 dB |
SNR Digital inputs (“A” weighted): |
>106 dB |
Distortion (THD+N) (20 Hz - 20000 Hz,160 W @ 8 ohm): |
<0.05 % |
Total number of inputs: |
9 |
Mic+Line inputs: |
4 |
Mic+Line connectors: |
Euroblock, RCA |
Digital inputs: |
5 |
Digital connectors: |
RCA, RJ45 |
Digital type: |
DANTE, S/PDIF |
General Purpose Inputs (GPI): |
5 |
Programmable GPI: |
Yes |
Signal output number: |
1 |
Signal output connectors: |
RCA |
General Purpose Outputs (GPO): |
5 |
Protocols for system integration: |
AMX, Control4, Elan, Q-SYS, RTI, Symetrix, URC |
Power consumption (MAX): |
150 W |
Rack mounting: |
1/2 19", 1U , Optional rack mounting accessory required |
Dimensions: |
1.73" x 8.66" x 12.56" |
Weight: |
6.17 lbs |
