RCF ART 712-A MK5 12" Active Speaker

Description
Tech Specs
Delivery & Returns

Description

ART 712-A MK5 is a unique product in its category. The 1.75" compression driver offers unique vocal clarity and sound projection. The 12” woofer offers an extremely linear response and a precise, deep low frequency control. The transducers are produced using the most advanced assembly technologies. The amplifier delivers 1400 watts and is controlled by a DSP that takes care of crossover, equalisation, phase control, soft limiting and speaker protections.

RCF's Class-D power amplifier technology packs huge performance operating with high efficiency into a lightweight solution. ART 7 amplifiers deliver ultra-fast attack, realistic transient response and impressive audio performance. The amplifier features a solid mechanical aluminium structure which not only stabilises the amplifier during transportation but also helps the fan-less heat dissipation. All the ART 7 amplifiers present SMPS power supply section in order to produce maximum output and minimum transportation weight.

Lightweight and powerful, RCF drivers are a true reference for high performance. All transducers are designed by RCF engineers in Italy for maximum reliability and perfectly matched components.

High Frequencies

The new 1.75" compression driver voice-coil design with Polyimide-Kapton dome features a new bonding technology and reinforced ribs making it 10 times more durable than previous designs. The redesigned phase plug increases sound clarity, enhancing transient response and improving coupling with the low-frequency transducer.

Low Frequencies

Low-frequency transducer design gains more stability over higher currents, with less distortion, and is highly efficient in terms of heat dissipation. RCF quality control is very strict. Our woofers are tested with a 200 hours continuous signal to stress the transducer at extreme levels. Only the best woofer design can fit ART 7.

Bring ART With You

The sturdy, ergonomic cabinet is easy to carry, thanks to either the handle at the top or the practical handles on both sides. The base of each speaker includes a steel pole socket for mounting on a stand or on a subwoofer pole. Stability and safety are assured. The rear of the cabinet is shaped to also be used as a floor monitor. Internal reinforcement prevents any deformation of the cabinet.

Features

129 dB Max SPL
1400 WATT 2-way peak power
90° x 60°, Wide dispersion constant directivity horn
Innovative DSP Processing
1,75" Compression Driver
12" Woofer
FiRPHASE Technology
XBOOST Low Frequencies Enhancer

Why We Like This

The 12" woofer provides additional low-end compared to smaller models while maintaining clarity through the compression driver. The combination of DSP, portability, and flexible mounting makes it suitable for a wide range of live sound setups.

FAQs

Q: Is this speaker powered or passive?
It is an active speaker with a built-in 1400W amplifier.

Q: Can it be used as a stage monitor?
Yes. The cabinet design allows it to be positioned as a floor monitor.

Q: Does it require an external amplifier?
No. The built-in amplifier powers the speaker.

Based in Chicago, IL, Gear Club Direct supports DJs, musicians, and audio professionals every day with reliable gear and knowledgeable service you can trust.

Tech Specs

Speaker Type:	Active Loudspeaker
Configuration:	2-Way
Total Output Power:	700 W RMS / 1400 W Peak
LF Driver:	1x 12" / 30.5 cm Woofer Voice Coil: 2.5" / 63.5 mm
HF Driver:	1x 1" / 51 mm Mylar Dome Tweeter Voice Coil: 1.75" / 44.45 mm
Frequency Range/Response:	50 Hz to 20 kHz
Maximum SPL:	129 dB
Coverage Angle:	90° H x 60° V
AC Input Power:	100 to 120 VAC, 50 / 60 Hz (T 6.3 A L 250 V) 200 to 240 VAC, 50 / 60 Hz (3.15 A L 250 V)
AC Power I/O:	1x VDE Input
Dimensions:	25 x 15.2 x 14.3" / 63.5 x 38.6 x 36.3 cm
Weight:	39.2 lb / 17.8 kg
