Description
PL 50EN is a ceiling speaker featuring a flameproof steel back can, designed for recess installation into ceilings or panels. It is especially suitable for broadcasting alarm messages thanks to the highly intelligible sound reproduction and its resistance to high temperatures reached during fires. The terminal connection blocks, for input and output flameproof cables, are made of ceramic material. A thermal fuse protects the integrity of the line in case of heat affecting the speaker. Ground screw available (if needed). Cables inside speaker made using flameproof leads.
Features
- 5" fullrange transducer.
- Power selectable (100 V): 6 W – 3 W – 1.5 W – 0.75 W.
- 92 dB sensitivity.
- Colour white RAL 9016.
- Steel frame, grille and back can.
- In/out ceramic terminal block.
- Thermal fuse protection.
Why We Like This
The integrated fire dome and safety-focused design make it a strong choice for compliant, high-reliability ceiling installations.
FAQs
Q: What is the purpose of the metal fire dome?
It provides additional fire protection and helps maintain system integrity during high temperatures.
Q: What type of system is this speaker designed for?
It is designed for 100V line distributed audio and voice alarm systems.
Q: How is it installed?
It is designed for recessed ceiling installation.
Based in Chicago, IL, Gear Club Direct supports installers and audio professionals with reliable gear and expert service you can trust.
Tech Specs
Frequency Response (-10dB): |
130 Hz - 15000 Hz |
Max SPL @ 1m: |
100 dB |
Max SPL @ 4m: |
88 dB |
Coverage angle: |
160° |
System Sensitivity: |
92 dB |
System Sensitivity 1W @ 4m: |
80 dB |
Amplification: |
Full Range |
Power Handling: |
6 W |
Peak Power Handling: |
24 W PEAK |
Protections: |
Thermal fuse |
Recommended Amplifiers: |
DXT 3000, DXT 4000, DXT 7000 |
Fullrange: |
1 x 5.0'' |
Input connectors: |
Ceramic screw terminals |
Output connectors: |
Ceramic screw terminals |
Constant Voltage Transformer: |
100 V |
Dimensions: |
5.63" x 4.92" x 7.13" |
Weight: |
2.98 lbs |
