Description
The Concorde DJ is considered the jack-of-all-trades, boasting accurate sound reproduction and excellent groove handling. Not only does the cartridge have a most sufficient tracking ability, it also provides the DJs with the most needed stringency and very low record wear.
Features
Excellent groove handling
Accuracy level
The DJ is great for any style of music. It has a spherical stylus and an extremely balanced cantilever that provides outstanding rigidity. Not only does the cartridge have a most sufficient tracking ability, it also provides the DJs with the most needed stringency and very low record wear. All in all: improved tracking, alongside of accurate sound reproduction and an excellent groove handling.
Output
The Concorde MKII DJ cartridge guarantees exceptional sound quality and precise tracking capabilities. Additionally, it offers a balanced output of 6 mV and remarkable transparency across the entire sonic spectrum.
Musical combo for your live sets
The DJ in action
DJ ND presents a musical combo which can be used to spice up your livestreams and podcasts.
Tech Specs
Brand: |
Ortofon |
Cantilever material: |
Aluminium |
Cartridge weight: |
18,5 g |
Channel balance at 1 kHz: |
1 dB |
Channel separation at 1 kHz: |
22 dB |
Compliance, dynamic, lateral: |
14 μm/m N |
Configuration: |
Single |
EAN: |
5705796013634 |
Internal impedance, DC resistance: |
700 Ohm |
Internal inductance: |
450 mH |
Manufacturer: |
Ortofon |
Manufacturer SKU: |
01420100 |
Model: |
dj-single |
Output voltage at 1 kHz, 5cm/sec: |
6 mV |
Product Model: |
DJ |
Recommended load capacitance: |
200-600 pF |
Recommended load resistance: |
47 kOhm |
Replacement stylus: |
Stylus CC MKII DJ |
Stylus tip radius: |
R 18 μm |
Stylus type: |
Spherical diamond |
Tracking ability at 315 Hz: |
100 μm |
Tracking force range: |
3 - 5 g |
Tracking force, recommended: |
4 g |
