Description

Peak is an eight-voice desktop polyphonic synthesiser built around New Oxford Oscillators that combine the best of analogue sound and digital flexibility – including inbuilt and custom digital wavetables. With a resonant multi-mode analogue filter for each voice, and three separate points of distortion per voice, it’s truly the best of both worlds. Polyphonic aftertouch, an extensive mod matrix, and two dedicated Animate buttons allow for endlessly expressive performances, while lush onboard reverb, delay and chorus round off a formidable addition to any sound designer’s arsenal.

Features

Digital where it counts — Digital FPGA-generated New Oxford Oscillators for analogue-style, wavetable and FM synthesis
Analogue where it matters — an analogue filter, analogue VCAs and three stages of analogue distortion per voice
High-quality digital effects — stunning reverb, delay, and chorus effects are instantly accessible via the effects section
Extensive modulation system — 16-slot modulation matrix and 16 direct assignments controllable from the front panel
Wavetable Editor — featuring drawing tools and a Live Edit mode, so you can draw your own oscillator shapes and preview them in real time

Why We Like This

Broaden out your electronic music, draw in new influences and take artistic risks. The modulation system puts the most frequently used assignments right at your fingertips in the main controls. More elaborate movements and secondary ‘via’ assignments are made just a few menu button presses away.

FAQs

Q: What software or system requirements does Novation specify?
A: Ableton Live Lite is included Peak is a USB-MIDI class compliant device

Q: What power requirements are listed?
A: Maximum power consumption 12V DC 1A

Based in Chicago, IL, Gear Club Direct supports musicians, integrators, and creators every day with reliable gear and expert service.

Tech Specs

Arpeggiator:	Arpeggiator w/ key latch – 33 patterns
Audio Outputs:	1/4" jack sockets for left and right outputs
CV Input:	3.5mm jack socket for CV in
Chassis:	Metal chassis with American walnut wooden end cheeks
Chorus:	Chorus - 3 types
Class Compliance:	USB-MIDI class compliant
Control Knobs:	42 Control knobs
Data Encoders:	2 Data encoders
Delay:	Delay with 16 types of delay sync, LP and HP damping, slew and stereo
Display:	OLED display
Distortion:	Analogue distortion
End Pieces:	Metal magnetic inset end pieces
Filter - Filter Modes:	Low-pass / band-pass / high-pass
Filter - Filter Slope:	12/24dB slope
Filter - Filter Type:	1x State variable OTA filter per voice
Filter - Post-filter Distortion:	Post-filter distortion
Filter - Pre-filter Overdrive:	Pre-filter overdrive
Function Buttons:	30 Function buttons (not lit)
Function Buttons 2:	16 Function buttons (lit)
Headphone Output:	1/4" jack socket for headphone output
Hold Button:	2 Animate buttons plus hold button
Included Software:	Ableton Live Lite is included
Knob Caps:	Rubberised knob caps with spun metal discs
LED Indicators:	90 Indicator LEDs
MIDI I/O:	MIDI In / Out / Thru
Modulation - Modulation Routing:	Each slot has 2 sources to 1 destination
Modulation - Modulation Slots:	16 modulation slots per patch
Patches:	Patch storage - up to 512 on hardware (ships with 256 factory patches)
Pedal Inputs:	2 1/4" jack socket for continuous or switched pedals
Per voice - Envelopes:	1 Amp envelope and 2 mod envelopes
Per voice - Filter:	1 Filter
Per voice - LFOs:	2 LFOs
Per voice - Noise Generator:	1 noise generator
Per voice - Oscillators:	3 oscillators
Per voice - Ring Modulator:	1 ring modulator
Polyphony:	8 voice polyphonic (voice modes available unison etc.)
Portamento:	Glide
Power Requirement:	Maximum power consumption 12V DC 1A
Power Supply:	Power supply connector
Power Switch:	Power switch
Product Type:	Polyphonic Desktop Synthesizer
Reverb:	Reverb - 3 types
Security Slot:	Kensington Security Slot
Sliders:	All knobs (excl. volume), sliders and most buttons transmit and receive MIDI cc commands for external control and mapping
Timbrality:	Mono-Timbral
USB:	USB B 2.0 / MIDI comms only (no bus-power)
Voice Modes:	5 Voice Modes - Mono, MonoLG, Mono2, Poly, Poly2
Volume Control:	1 Volume knob
