Description
Provide tight and transparent sound with the Lab.Gruppen FP 14000 BP, a 2 RU, two-channel 14,000W amplifier that can drive professional-grade sound systems of any size. The FP 14000 provides two channels of extremely powerful amplification using Lab-Gruppen's patented Class-TD output stage, which combines the sonic purity of Class-B with the efficiency of Class-D. To maximize headroom in any application, the FP 14000 offers adjustable input gain along with Lab.Gruppen's exclusive Voltage Peak Limiter (VPL). Adjustable on a per-channel basis, VPL optimizes the output for any load, from a single massive subwoofer to a series of HF compression drivers.
Features
- 14,000W, 2-channel amplifier with up to 7000W output per channel and NomadLink network for monitoring and control
- Selectable gain plus scalable Voltage Peak Limiter (VPL) and bridge-mode operation allow custom configuration for any application
- Proven and reliable Class-TD output stage delivers Class A/B audio quality with Class-D efficiency
- Regulated Switch Mode Power Supply (R.SMPS) ensures constant power output at all times
- Intuitive DeviceControl software monitors and controls key functions via the NomadLink network
- Comprehensive protection scheme including current, voltage, DC, temperature, short circuit, and open load warnings
- Efficient Intercooler copper cooling system dissipates more heat for extended peak output
- Two balanced analog audio inputs and two link outputs on Neutrik XLR connectors
- Binding post output connectors
- Removable dust filter grilles for increased air circulation
- Rugged 2 RU rackmount chassis for durability in touring applications
Regulated Switch Mode Power Supply
- The Regulated Switch Mode Power Supply (R.SMPS) has been updated to provide more sustained high power, during extended bursts of low-frequency content, while at the same time, ensuring stable rail voltages, even with wide fluctuations of external mains voltage.
- The forceful, high-current (83A peak) output stage relies on LAB GRUPPEN’s patented Class TD topology, a breakthrough in amplifier technology that approaches the efficiency of Class-D while retaining the sonic purity of proven Class-B designs.
- A highly refined and efficient circuit layout further optimizes the interaction of R.SMPS and Class TD to produce the unprecedented power density of the FP 14000.
Intercooler Technology
- To keep its cool under extreme demands, the FP 14000 relies on LAB GRUPPEN’s proprietary Intercooler. This innovation uses thousands of copper fins to multiply the exposed heatsink surface’s rapid heat dissipation.
- All output devices are mounted transverse to the airflow for uniform cooling, resulting in the FP 14000 delivering LAB GRUPPEN’s trademark "all the power, all the time" with no degradation of sonic performance.
Advanced Protection + Comprehensive Warning
- The comprehensive warning and protection features on the FP 14000 safeguard output circuits and connected loads while also extending amplifier life and minimizing the chance of service interruptions.
- Whether it’s a matter of faulty wiring, improper use, or extreme ambient temperatures, the FP 14000 gives clear indication of any problems.
- Automatic protection measures engage only at critical thresholds.
- Operating conditions are re-checked every six seconds and, if a fault is detected, normal operation is resumed when measurements return to nominal.
NomadLink Network
- The FP 14000 is shipped with a NomadLink network interface as standard.
- In conjunction with DeviceControl software, NomadLink allows comprehensive monitoring of amplifier status (including fault or warning indications) and also enables remote control of power on/off, channel mute, and channel solo functions.
- NomadLink is compatible with popular third-party control platforms.
- The separate NLB 60E NomadLink Bridge & Network Controller is required.
Tech Specs
Number of Channels: |
2 |
Amplifier Class: |
Class-TD |
Analog Audio I/O: |
2x XLR 3-Pin Female Balanced Input 2x XLR 3-Pin Male Balanced Line Thru/Output 2x Binding Post Pair 1-Pin Speaker Output |
Digital I/O: |
No |
Network I/O: |
2x etherCON/RJ45 Ethernet |
Rackmount Size: |
2 U |
