Description
The ZONA PROFILE DW was created for designers, programmers, and production teams who demand beautifully controlled white light in a modern ellipsoidal fixture. Unlike traditional ellipsoidal fixtures that are limited to fixed 3200K tungsten or 5600K daylight output, the ZONA PROFILE DW gives lighting professionals the flexibility to precisely tune white light from 2700K to 7500K, allowing a single fixture to adapt seamlessly across theatre, broadcast, worship, studio, architectural, and live production environments. Powered by a dedicated 350W warm white and 350W cool white LED system, the ZONA PROFILE DW delivers exceptionally balanced white light with smooth variable CCT control and outstanding color fidelity with CRI values up to 97. From warm tungsten-inspired tones to crisp daylight whites, it produces natural-looking illumination with accurate skin tones and refined on-camera performance that today's productions demand. Whether illuminating a stage, a broadcast set, a house of worship, or an architectural environment, the ZONA PROFILE DW delivers refined white-light performance, creative flexibility, and dependable operation for today's demanding productions.
Features
- High-output 350W warm white and 350W cool white LED engine for rich, natural white light reproduction.
- Precision variable CCT adjustment from 2700K to 7500K with exceptional color rendering up to CRI 97.
- Ultra-smooth 16-bit dimming with 6 dimming modes and 4 selectable dimming curves for seamless fades and precision control.
- Flicker-free performance with adjustable PWM for flawless results across virtually any camera system.
- Virtually silent operation with Auto, Fast, Slow, and Fan-Off cooling modes, ideal for studio, film, theatre, and other noise-sensitive environments.
- RDM-enabled for seamless remote configuration, monitoring, and system integration.
- Advanced adjustable yoke design for precise positioning and simplified installation in low-clearance environments.
- Compatible with standard ellipsoidal lenses, gel frames, and gobo holders for seamless integration with industry-standard accessories (lens not included).
Why We Like This
ZONA Profile DW Variable White LED Ellipsoidal gives lighting designers practical control over clean white light and controlled venue coverage. Optics - o more Size: 90mm (outside), 70mm (image), 2.5 mm (max. thickness). That gives the fixture a clear role in a programmed lighting rig.
FAQs
Q: What light source does the JP4008 use?
A: 350W warm white and 350W cool white LED engine for rich, natural white light reproduction.
Q: What beam or zoom range does the JP4008 provide?
A: Optics - o more Size: 90mm (outside), 70mm (image), 2.5 mm (max. thickness).
Q: How can the JP4008 be controlled?
A: Control - Control Protocol: DMX, RDM.
Based in Chicago, IL, Gear Club Direct supports musicians, integrators, and creators every day with reliable gear and expert service.
Tech Specs
Box Content: |
1 x ZONA Profile DW w/ Shutter Barrel (Lens Sold Separately); 1 x TRUE1 Power Cable; 1 x User Manual; 1 x Safety Cable; 1 x Gobo Holder |
Brand: |
Jmaz Lighting |
Color System: |
CRI (Ra) 95 @ 3200K; CRI (Ra) 95 @ 5600K |
Color System - CRI (Ra): |
97 @ 2700K |
Color System - Color Temperature (At Full): |
4687K |
Color System - Linear CCT: |
2700K - 7500K |
Control - Control Protocol: |
DMX, RDM |
Control - Optional Add-On Wireless DMX: |
CRMX USB- Powered by LumenRadio (SKU: JP5001) |
Control - Personalities: |
1/3/4/8/11 |
Country of Origin: |
China |
Designed and Engineered: |
California |
Die-Cast Aluminum Body - Exterior Finish: |
Black |
Dimensions: |
21.6″ x 10.8″ x 8.7″ / 551.2 x 276 x 221mm |
Dynamic Effect - Dimmer: |
0 - 100% smooth linear electronic dimming |
Dynamic Effect - Linear Dimmer: |
0-100% Smooth Linear LED |
Dynamic Effect - Strobe Shutter: |
1-25 Hz Variable |
Electrical: |
o Up to 5 units @110V with a 20A circuit; o Up to 9 units @208V with a 20A circuit; o Up to 11 units @230V with a 20A circuit |
Electrical - Fuse: |
T6.3A/250V |
Electrical - Input Voltage: |
100 - 240V AC, 50/60Hz (Auto Ranging with Active PFC) |
Electrical - Power Consumption: |
350W |
Electrical - o Maximum Temperature: |
60 ° C ( 140 ° F) |
Electrical - o Minimum Temperature: |
- 10 ° C ( 14 ° F) |
Full Product Specifications: |
Technical specifications Light Source • 350W (1 x 350W) Cool White LED • 350W (1 x 350W) Warm White LED • LED Life Expectancy: 50,000 Hrs Color System • Linear CCT: 2700K - 7500K • Color Temperature (At Full): 4687K • CRI (Ra): 97 @ 2700K • CRI (Ra) |
Item Height: |
8.7 in |
Item Length: |
20.55 in |
Item Weight: |
18.62 lbs |
Item Width: |
10.8 in |
Light Source: |
350W (1 x 350W) Cool White LED; 350W (1 x 350W) Warm White LED |
Light Source - LED Life Expectancy: |
50,000 Hrs |
Manufacturer: |
JMAZ Group |
Master Pack Cartons: |
1 |
Master Pack Height: |
9.62 in |
Master Pack Length: |
24.25 in |
Master Pack Quantity: |
1 |
Master Pack Weight: |
23.47 lbs |
Master Pack Width: |
11.1 in |
Model: |
JP4008 |
Optics: |
o 19° Degree; o 26° Degree; o 36° Degree; o 50° Degree |
Optics - o Maximum Size: |
90mm (outside), 70mm (image), 2.5 mm (max. thickness) |
Optics - o Size B: |
86 mm (outside), 64.5 mm (image), 2.5 mm (max. thickness) |
Physical - Cable Length: |
Power 5ft (1.5M) |
Physical - Cooling: |
Advanced Ultra Quiet Fan |
Physical - Data Connectors: |
NEUTRIK 5-Pin DMX |
Physical - IP Rating: |
20 |
Physical - Power Connection: |
US Edison (ETL listed) plug to REAN IP65 TRUE1 |
Physical - Power Input: |
REAN IP65 True1 |
Physical - Power Output: |
REAN IP65 True1 |
Product Data Sheet: |
https://www.dropbox.com/scl/fi/ddtl2mknclehotaocjyup/JMAZ-PROFESSIONAL-Zona-Profile-DW-Product-Data-Sheet.pdf?rlkey=uvgx1bol9zc2cg7a2g6h3tlev&e=1&st=jpgm3mm6&dl=0 |
Product Name: |
Zona Profile DW |
Product Type: |
Professional Lighting Product |
Prop 65 Compliant: |
Yes |
SKU: |
JP4008 |
Shipping Height: |
9.62 in |
Shipping Length: |
24.25 in |
Shipping Width: |
11.1 in |
UPC: |
618528599878 |
Video URL: |
VIDEO |
Website URL: |
https://jmazprofessional.com/Products/zona-profile-dw/ |
o High speed electronic shutter and strobe: |
o 0-25Hz shutter/ strobe effect with variable speed; o Preset pulse strobe effect with variable speed |
o Random strobe effect with variable speed - Built in-Auto Programs: |
Yes |
o Random strobe effect with variable speed - Color Temperature: |
2700K - 7500K |
o Random strobe effect with variable speed - Dimming Curves: |
4 |
o Random strobe effect with variable speed - Dimming Modes: |
6 |
