Description
The JBL LCT 81C/TM is a low-profile lay-in 2 x 2-foot ceiling tile loudspeaker package designed for clear speech reinforcement and distributed audio installations. This white two-speaker set uses efficient 8-inch dual-cone drivers, supports 70V, 100V, or 8-ohm amplifier systems, and installs directly into compatible ceiling tile grids.
Features
- Includes two white low-profile lay-in 2 x 2-foot ceiling tile loudspeakers
- Highly efficient 8-inch dual-cone full-range driver in each loudspeaker
- Designed for high speech intelligibility
- 40 W continuous program power capacity at low impedance
- Supports 70V, 100V, or 8-ohm amplifier systems
- 70V transformer taps: 10 W, 5 W, 2.5 W, and 1.3 W
- 100V transformer taps: 10 W, 5 W, and 2.5 W
- 100 Hz to 16 kHz frequency range
- 100-degree conical coverage at 1 kHz
- 96 dB sensitivity and 114 dB peak SPL
- Bare-wire speaker connection
- UL certified steel enclosure
Why We Like This
The LCT 81C/TM provides a practical, low-profile solution for paging, background music, and speech reinforcement in suspended-ceiling spaces. Its 70V, 100V, and 8-ohm compatibility gives installers flexibility across distributed and low-impedance system designs.
FAQs
Q: How many speakers are included with the JBL LCT 81C/TM?
A: This package includes two white JBL LCT 81C/TM ceiling tile loudspeakers.
Q: Does the JBL LCT 81C/TM work with 70V and 100V systems?
A: Yes. It includes transformer taps for both 70V and 100V distributed audio systems.
Q: What size driver is used in the JBL LCT 81C/TM?
A: Each loudspeaker uses one 8-inch dual-cone full-range driver.
Q: What ceiling grid size is the JBL LCT 81C/TM designed for?
A: It is a low-profile lay-in loudspeaker designed for 2 x 2-foot ceiling tile grids.
Based in Chicago, IL, Gear Club Direct supports musicians, integrators, and creators every day with reliable gear and expert service.
Tech Specs
Brand: |
JBL |
Manufacturer: |
JBL |
Model: |
LCT 81C/TM |
SKU: |
LCT |
Product Type: |
Low-Profile Lay-In Ceiling Tile Loudspeaker |
Active/Passive: |
Passive |
Number of Included Speakers: |
2 |
Speaker Configuration: |
Full-Range |
Power Handling: |
40 W Program at Low-Z |
Constant Voltage / Transformer Taps: |
100V: 10 / 5 / 2.5 W; 70V: 10 / 5 / 2.5 / 1.3 W |
Impedance: |
8 Ohms, Transformer Bypassed |
Full-Range Driver: |
1 x 8-inch / 203.2 mm Coaxial Cone |
Full-Range Voice Coil: |
1-inch / 25.4 mm |
Frequency Range: |
100 Hz to 16 kHz, -10 dB |
Maximum SPL: |
114 dB Peak |
Sensitivity: |
96 dB |
Coverage Angle: |
100 degrees at 1 kHz, Conical |
Inputs/Outputs: |
Wire Lead Speaker |
Certifications: |
UL |
Color: |
White |
Mounting: |
4 x Bracket Point, Side |
Mount Surface Thickness: |
Up to 4 inches / 101.6 mm |
Construction Material: |
Steel |
Length: |
23.4 inches / 595 mm |
Shipping Length: |
27.25 inches |
Shipping Width: |
27 inches |
Shipping Height: |
12 inches |
