Description
The EAW RSX212L is a self-powered line-array loudspeaker within EAW's RSX family for scalable professional sound-reinforcement systems. It fits engineered arrays in which coverage, processing, and system deployment are planned together.
Features
- Driver configuration: LF: 2 × 12 in cone, 2.5 in voice coil; HF: 2 × 1 in exit, 1.7 in voice coil compression drivers
- Operating range: 50 Hz to 19 kHz
- Maximum SPL: 142 dB
- Nominal coverage: 90° H × 12° V
- Integrated amplification: LF: 1000 W; HF: 500 W
- Operating mode: Bi-amp LF/HF; DSP with EAW Focusing and DynO
Why We Like This
The RSX212L is useful when integrated amplification and processing simplify deployment and reduce dependence on external amplifier channels.
FAQs
Q: Do I need a separate amplifier for the RSX212L?
A: No. Amplification is built into the RSX212L. Plan for the correct AC power and signal connections before using it.
Q: Will the RSX212L work on different mains voltages?
A: Yes. The RSX212L accepts 100–240 V AC. Check the AC connector and local power requirements before use.
Q: How do I connect the RSX212L to my audio system?
A: The RSX212L connects through XLR input with loop-through; etherCON/RJ-45 network. Check EAW's wiring and pinout information before making cables or terminations.
Q: What do I need to add the RSX212L to an array?
A: Plan the array in EAW software and confirm AC power, processing, signal distribution, and approved rigging hardware before deployment.
Based in Chicago, IL, Gear Club Direct supports musicians, integrators, and creators every day with reliable gear and expert service.
Tech Specs
AC Connector: |
Neutrik powerCON |
AC Frequency: |
50 Hz to 60 Hz |
AC Voltage: |
100–240 V |
Amplifier Output: |
LF: 1000 W; HF: 500 W |
Amplifier Type: |
Modified Class D |
Audio Connections: |
XLR input with loop-through; etherCON/RJ-45 network |
Driver Configuration: |
LF: 2 × 12 in cone, 2.5 in voice coil; HF: 2 × 1 in exit, 1.7 in voice coil compression drivers |
Driver Protection: |
Integral DSP limiting |
EAW Technologies: |
EAW Focusing, DynO, Concentric Summation Array (CSA) |
Finish: |
Black |
Frequency Response: |
50 Hz–19 kHz |
Maximum SPL: |
142 dB |
Nominal Coverage: |
90° H × 12° V |
Power Consumption: |
Idle: 26 W; Peak draw: 250 W |
Product Height: |
14 in |
Product Length: |
20.38 in |
Product Type: |
Powered Line Array Loudspeaker |
Product Width: |
32 in |
