db Technologies LVX XM 15" Professional Stage Monitor

Write a Review
$1,883.00
db Technologies LVX XM 15" Professional Stage Monitor
db Technologies LVX XM 15" Professional Stage Monitor
db Technologies LVX XM 15" Professional Stage Monitor
db Technologies LVX XM 15" Professional Stage Monitor
db Technologies LVX XM 15" Professional Stage Monitor
db Technologies LVX XM 15" Professional Stage Monitor
db Technologies LVX XM 15" Professional Stage Monitor
db Technologies LVX XM 15" Professional Stage Monitor
db Technologies LVX XM 15" Professional Stage Monitor
db Technologies LVX XM15 - IMG01
SKU:
LVX XM15
Shipping:
Free Shipping
Current Stock:

Description

The LVX XM 15” Professional Stage Monitor from dB Technologies meet all live music and touring requirements where sound reinforcement systems must be lightweight, portable, impact-resistant and easily adaptable to different stage necessities.

Features

  • Design enhances the benefits of coaxial horn wedges conceptHorn not only shapes high frequencies’ directivity but also acts as a phase plug for the woofer, boosting and lighting up the vocal band, thanks also to the advanced DSP featuring FIR filters processingHorn contributes to deliver a bright audio performance with a uniform throw pattern, and contributes to reduce the overall dimensions of the system and protect the internal components, reinforcing the cabinet structureFeatures an advanced DSP offering eight variable presets in order to easily adapt to different stage requirements and to the varying demands of vocalists, instrumentalists as well as audio playback applicationsCabinet is constructed in sturdy plywood and comes with 2 integrated side handles to allow easy transport and stage setup operationsPole mount cup on one side allows to mount the system on a pole for vertical use

What's in the box

  • Limited 2-Year Warranty

Specifications

Active or Passive Active
Speaker Type 2-way coaxial stage monitor
Amplifier Technology Digipro G3
Frequency Response 58 to 17,800 Hz (-6 dB)
Power Capacity Power RMS: 600 W
Peak Power: 1200 W
Maximum Sound Pressure Level (SPL) 128 dB
Nominal Sensitivity Not Specified by Manufacturer
Impedance Not Specified by Manufacturer
Crossover Not Specified by Manufacturer
Directivity 90° x 70°
Low Frequency Driver
High Frequency Driver
Enclosure Material Plywood with PVC cover
Metal grille
Input Connections Mains Connections: PowerCON in/link
Signal Input: 1 x Combo In (XLR/Jack)
Signal Output: 1 x XLR link Out
USB connector Mini USB B-type (service only)
Power Supply SMPS with PSU Auto-range
Power Connection Type PowerCon In/Link
Cooling Convection
Processor Controller: DSP 56-bit
Converter AD/DA: 24-bit/48 kHz
System Presets: 8
Limiter: Peak, RMS, Thermal
Processing (filters): FIR linear phase
Controls: Rotary 8 positions, MIC/LINE switch
Handles 2, chassis integrated
Pole Mount D36 mm
Dimensions
Weight   Packaging Info

Package Weight 60.0 lb Box Dimensions (LxWxH) 29.0 x 21.5 x 17.5"
