Description
Ready for a wide range of short and long throw applications, the Chauvet Professional Maverick Force X Profile is an intense, compact moving head fixture with superb dimming performance, an expansive 18:1 zoom, and a full armory of features. The Maverick Force X Profile is built to withstand the rigors of on-the-road wear and tear.
The fixture features a single 520W LED light engine that ensures no hot spots, only perfectly even output at every angle. Maverick Force X Profile goes flat out from narrow beams to wide spots, while producing excellent color rendering and offering lighting designers a full effects wheelhouse for layering gobo, prism, and smooth dimming. Draw on Maverick Force X Profile to release stunning textured looks, send totally solid beams, and hit the deepest colors.
Features
- Fully featured, compact, and lightweight 520 W LED yoke profile fixture including CMY color mixing, a color wheel, zoom optics, framing shutters with rotation, and two gobo wheels, one rotating, and one static
- 16-bit dimming of the master dimmer for smooth control of fades
- 65,000 PWM for use with the fastest frame cameras, but still maintains fantastic dimming
- Variable CMY color mixing system to create a wide palette of colors
- DMX, CRMX, sACN, and Art-Net for full flexibility of control options
- RDM-enabled for remote addressing and troubleshooting
- 3.5° to 57.3° zoom range for variable beam sizes
- Iris, 5-facet prism, and frost for beam control
Additional Features
- 4-blade framing shutters with dual-axis movement, full wipe, and 120-degree total module rotation
- True-1 compatible power input
- Three setup menu presets and preset sync for cross-loading to multiple like fixtures for easy shop setup
- USB slot for software uploads
- Battery backup display with auto-rotate depending on fixture orientation
- Failsafe Ethernet connectivity allows data to pass even if fixture power is lost
- NFC for quick/easy fixture setup in the shop or in the field
Tech Specs
Fixture Type: |
Moving Head |
Light Source: |
1x White LED - 520 W / 4.2 A |
Expected Lamp Life: |
50,000 Hours |
Colors: |
CTB (Color Temperature Blue), CTO (Color Temperature Orange), HCRI (High CRI), Magenta, Orange, Red |
Color Temperature: |
6966K |
Lumen Output: |
18,963 Lumens (Output) |
Beam Angle: |
3.4 to 52.2° |
Field Angle: |
3.7 to 55.3° |
Focus: |
Motorized |
Strobe Rate: |
0 to 25 Hz |
Gobos: |
9x Removable Metal Gobo 1x Spot/Open |
Tilt Ranges: |
180° / 270° / 90° |
Pan Ranges: |
540° / 360° / 180° |
Control Protocols: |
DMX512, CRMX, RDM, Art-Net, sACN |
DMX Channel Modes: |
31 / 47-Channel |
AC Input Power: |
100 to 240 VAC, 50/60 Hz |
AC Power Connector: |
Input: 1x Seetronic IP-Rated Output: 1x Seetronic IP-Rated Plug Type: NEMA 1-15 Cord Length: 5' / 1.5 m |
Fuse: |
F 10 A 250 V |
F 10 A 250 V: |
120 VAC, 60 Hz: 595 W / 4.64 A 208 VAC, 60 Hz: 576 W / 2.63 A 230 VAC, 50 Hz: 580 W / 2.44 A |
Battery Type: |
3.7 V Lithium-Ion (Display Backup Power Only) |
Battery Capacity: |
500 mAh |
Battery Charging Time: |
5 Hours |
Environmental Resistance: |
Dust-Resistant (IP20) |
Mounting: |
Floor Base, Omega Bracket |
Included Accessories: |
1x Power Cable |
