Chauvet DJ Shocker Panel FX IP

Description
Delivery & Returns

Description

Shocker Panel FX IP instantly shifts between strobe, wash, and blinder looks as easily as it moves between indoor and outdoor events. 8 sections of bright RGB color + an intense 8-section cool white LED strip add up to endless eye candy effects from one compact IP66-rated powerhouse. Setups are fast and secure with a digital touch display for choosing dazzling built-in effect macros and setting password access, all with the press of a button. Wherever they take this rugged unit, event managers and entertainers will wow party-goers with Shocker Panel FX IP’s high output and fast transitions.

Highlights

Outdoor-rated versatile blinder, wash and strobe light, with compelling eye candy effects
Neutrik TRUE1 power input/output connections save setup time while maintaining water resistance
16 controllable sections (8 RGB + 8 white) provide creative programming flexibility
Robust IP-rated housing repels the elements in outdoor situations
Password-protected and touch-sensitive digital display
Trigger eye-catching, built-in macros via the display or DMX
Integrated GORE valve allows the fixture to breathe and prevents internal humidity build-up
Easily transported in the optional CHS-25 VIP gear bag

Specifications

DMX Channels:8, 18, 34 or 47
DMX Connectors:5-pin XLR
Light Source:
480 LEDs (tri-color) 2W, (1A), 50,000 hours life expectancy
32 LEDs (cool white) 1.8 W (0.5 A), 50,000 hours life expectancy
Strobe Rate:0 to 20 Hz
Beam Angle:119°
Field Angle:158°
Illuminance:1,131 lux @ 2 m
Lumens:13,626
IP Rating:IP66
Power Linking:6 units @ 120 V; 11 units @ 230 V
Input Voltage:100 to 240 VAC, 50/60 Hz (auto-ranging)
Power and Current:
238 W, 2 A @ 120 V, 60 Hz
231 W, 1 A @ 230 V, 50 Hz
Weight:10.4 lbs (4.7 kg)
Size:12.9 x 5.1 x 6.8 in (330 x 130 x 173 mm)
Approvals:CE, ROHS, MET
Startup Temperature: -4 °F to 113 °F (-20 °C to 45 °C)
Operating Temperature: -22 °F to 113 °F (-30 °C to 45 °C)
Cable Length: 5 ft (1.5 m)
Max Output Current: 12 A (6 units @ 120 V) (11 units @ 230 V)

What's Included

Shocker Panel FX IP
Power cable
Quick Reference Guide

Why We Like This

The Shocker Panel FX IP combines powerful RGB washes, intense white strobes, animated pixel effects, and rugged IP66 protection into one compact fixture. With professional-grade construction, advanced zoning, TRUE1 connectivity, and integrated GORE® technology, it's an excellent choice for both indoor and outdoor productions where reliability and visual impact are essential.

FAQs

Q: Is the Shocker Panel FX IP suitable for outdoor use?
Yes. It features a rugged IP66-rated housing designed for demanding outdoor environments.

Q: How many controllable lighting zones does it have?
The fixture offers 16 independently controllable sections, including 8 RGB zones and 8 cool white zones.

Q: What lighting effects can it produce?
It functions as a strobe, wash, blinder, and animated pixel effect fixture, all within one compact unit.

Q: What type of power connection does it use?
The fixture utilizes Neutrik TRUE1 power input and output connectors, providing secure, weather-resistant power distribution and convenient power linking.
