Description
Bring events to life with Intimidator Spot 360QD, the first CHAUVET DJ moving head with RGBL color technology. Its RGBL light engine delivers a wide color range, increased CRI, and crystal-clear optics, giving DJs, bands, and event professionals more creative freedom for any occasion. Dual rotating prisms create bold, room-filling effects, while motorized focus keeps gobos sharp from nearly any distance. Totem Mode keeps the action focused on the dance floor, and built-in wireless control makes setup easier with fewer cables. A lightweight carbon-fiber composite housing simplifies transportation and handling. MET certified for permanent installations, Intimidator Spot 360QD delivers elevated color, creative flexibility, and reliable performance for mobile events and entertainment venues.
Features
- Innovative moving head designed for the mobile entertainer or permanent installation
- Wide color range, increased CRI, and crystal-clear optics from the RGBL light engine
- Carbon fiber composite housing material is exceptionally strong, resists corrosion, and reduces weight
- Built-in D-Fi transceiver for wireless DMX or master/slave communications
- Built-in RF receiver for wireless control using the RFC or RFC-XL optional remotes
- Dual rotating prisms split the beam for great effects and cover a larger area
- Project crisp gobos from nearly any distance with the motorized focus
- Beams always remain on the dance floor using the built-in, innovative Totem mode
- PowerCON®-compatible power input/output connections saves setup time
- Onboard USB-C port allows for quick software updates
Why We Like This
This is a useful choice when the same rig has to handle different venues. Motorized focus lets you sharpen a gobo after positioning the fixture, while the two prism shapes give you different ways to spread the effect across the room.
FAQs
Q: Do I need a separate wireless DMX receiver?
A: The fixture has a built-in D-Fi transceiver, so it does not need an external D-Fi receiver. Wireless DMX control still requires a compatible D-Fi transmitting source.
Q: Are the RFC or RFC-XL remotes included?
A: No. Both are optional accessories. The built-in RF receiver lets you use either compatible remote without adding an external RF receiver.
Q: Can I install a custom gobo?
A: Yes. The rotating gobos are interchangeable. CHAUVET specifies a 24 mm outside diameter, a 20 mm image diameter, and a maximum thickness of 0.5 mm.
Q: Can I run it from a wired DMX controller?
A: Yes. The fixture supports 11- or 18-channel DMX operation and provides 3- and 5-pin XLR DMX connections.
Q: What is included for mounting?
A: Hanging brackets are included, along with the fixture, power cord, and Quick Reference Guide. Overhead installation requires suitable mounting clamps and a safety cable.
Based in Chicago, IL, Gear Club Direct supports musicians, integrators, and creators every day with reliable gear and expert service.
Tech Specs
Approvals: |
CE, RoHS, MET |
Beam Angle: |
17° |
Cooling: |
Fan-assisted convection |
DMX Channels: |
11 or 18 |
DMX Connectors: |
3- and 5-pin XLR |
Dimensions (L x W x H): |
12.5 x 8.6 x 17.1 in (319 x 220 x 435 mm) |
Firmware Update Port: |
USB-C |
Focus: |
Motorized |
Fuse: |
F 5 A; 250 V |
Gobo Size: |
24 mm outside, 20 mm image, 0.5 mm max thickness |
Gobos: |
7 + open (6 metal + 1 glass), rotating, interchangeable, indexing, slot-n-lock, continuous scroll at variable speeds |
Housing: |
Carbon fiber composite |
Illuminance: |
17,242 lux @ 2 m, 2,759 lux @ 5 m |
Included: |
Intimidator Spot 360QD; power cord; hanging brackets; Quick Reference Guide |
Input Voltage: |
100 to 240 VAC, 50/60 Hz (auto-ranging) |
Item Code: |
08012794 |
Light Source: |
1 LED (quad-color RGBL) 220W, (2.5A), 50,000 hours life expectancy. |
Lumens: |
4,474 |
Maximum Ambient Temperature: |
104°F (40°C) |
Model: |
Intimidator Spot 360QD |
Optional Controllers: |
RFC, RFC-XL |
Pan and Tilt: |
540° / 270° |
Pan and Tilt Ranges: |
540°, 360°, 180° pan/270°, 180°, 90° tilt |
Power Input/Output: |
powerCON-compatible |
Power Linking: |
4 units @ 120 V; 8 units @ 230 V |
Power and Current (120 V): |
339 W; 2.8 A; 60 Hz |
Power and Current (230 V): |
336 W; 1.4 A; 50 Hz |
Prisms: |
5-facet linear and 6-facet round; bidirectional rotation at variable speeds |
Product Type: |
RGBL LED Moving Head Spot |
RF Remote Compatibility: |
RFC; RFC-XL (sold separately) |
Strobe Rate: |
0 to 25 Hz |
UPC: |
781462231422 |
Wireless DMX: |
Built-in D-Fi transceiver |
