Description
Full-range environmental loudspeaker designed to blend with landscaping for in-ground or above-ground applications, such as shopping malls, outdoor restaurants, resorts and theme parks. Features 360° horizontal coverage and frequency range down to 60 Hz.
Features
- Low-Frequency: 1 × Bose 4.5 in (114 mm) environmental driver
- Power Handling, long-term continuous: 70/100V: 80 W / 8Ω: 30 W
- Frequency Range (-10 dB): 60 Hz – 15,000 Hz
- Coverage, Horizontal: 360°
- Ingress Protection: IP55
- Full-range environmental loudspeaker with one downward firing 4.5-inch (114 mm) advance composite environmental full-range driver for in-ground or above-ground mounting
- Cabinet shape acts as acoustic diffuser directing mid- and high-frequency energy out towards listeners. Base of loudspeaker acts as a tuned, multi-chambered ported enclosure
Why We Like This
The outdoor-rated enclosure gives the system designer more placement options for spaces that extend beyond the building.
FAQs
Q: What amplifier connection does it require?
A: The nominal impedance is 8Ω (transformer bypassed). Transformer settings: Transformer Taps, 100V: 10, 20, 40, 80 W, bypass; Transformer Taps, 70V: 10 W, 20 W, 40 W, 80 W, bypass.
Q: What installation items are included?
A: The listed items are (1) installation guide; (1) FreeSpace 360P Series II; (8) wire nuts.
Q: Does it need additional signal processing?
A: No Bose EQ required. For best performance, Bose EQ presets available..
Based in Chicago, IL, Gear Club Direct supports musicians, integrators, and creators every day with reliable gear and expert service.
Tech Specs
Calculated Maximum SPL @ 1 m: |
107 dB |
Color: |
Green |
Coverage, Horizontal: |
360° |
Coverage, Vertical: |
50° |
Driver Protection: |
Recommended high-pass filter 60 Hz with minimum 24-dB/octave filter, Presets available |
Frequency Range (-10 dB): |
60 Hz – 15,000 Hz |
Included Items: |
(1) installation guide; (1) FreeSpace 360P Series II; (8) wire nuts |
Ingress Protection: |
IP55 |
Low-Frequency: |
1 × Bose 4.5 in (114 mm) environmental driver |
Model: |
FreeSpace 360-P II In-Ground Loudspeaker Green |
Nominal Impedance: |
8Ω (transformer bypassed) |
Power Handling, Peak: |
70/100V: 320 W / 8Ω: 120 W |
Power Handling, long-term continuous: |
70/100V: 80 W / 8Ω: 30 W |
Product Type: |
Installation loudspeaker |
Recommended Signal Processing: |
No Bose EQ required. For best performance, Bose EQ presets available. |
Sensitivity (SPL/1 W at 1 m): |
87 dB |
Suspension/Mounting: |
3 × #10 (M4) holes in base, 3 × #10 (M4) screws required |
Transformer Taps, 100V: |
10, 20, 40, 80 W, bypass |
Transformer Taps, 70V: |
10 W, 20 W, 40 W, 80 W, bypass |
Unit of Sale: |
Each |
