Description
The AVM-1 sense microphone mounts discreetly into ceilings and provides an analog output over a balanced audio connection. Designed for use with AutoVolume compensation, as featured in select Bose sound processors, the microphone delivers a continuous ambient room noise reference.
Features
- Discreet, flush-mounted design blends seamlessly into common ceiling surfaces
- Omnidirectional condenser microphone capsule operates on phantom power and can be located up to 610 meters (2,000 feet) away from the sound processor
- Spring clips help make installation easy while keeping the microphone firmly in place
- Condensation cover protects wire terminals from moisture collection and ensures sustained operation in above-ceiling mounting locations
Why We Like This
An ambient-noise reference helps a compatible processor respond to changes in how busy the room becomes.
FAQs
Q: Which equipment does it work with?
A: Compatible with CSP-428 and CSP-1248
Q: What installation items are included?
A: The listed items are (1) AVM-1.
Q: How is it powered?
A: The specified power range is 48 VDC, 10 mA phantom power via ground terminal (typical).
Based in Chicago, IL, Gear Club Direct supports musicians, integrators, and creators every day with reliable gear and expert service.
Tech Specs
Audio Outputs, Analog — Channels: |
1 balanced, mic |
Audio Outputs, Analog — Connectors: |
(1) fixed 3-terminal bare-wire, 3.5 mm |
Color: |
White |
Compatibility: |
Compatible with CSP-428 and CSP-1248 |
Compatible with: |
CSP-428, CSP-1248 |
Electrical — Connectors: |
(1) fixed 3-terminal bare-wire, 3.5 mm |
Frequency Response: |
100 Hz – 6 kHz (±4 dB), relative level 1 kHz |
Included Items: |
(1) AVM-1 |
Maximum Input Level: |
115 dB at 1 kHz |
Model: |
AVM-1 Sense Microphone |
Phantom Power: |
48 VDC, 10 mA, via ground terminal (typical) |
Power Range: |
48 VDC, 10 mA phantom power via ground terminal (typical) |
Product Type: |
Ambient sensing microphone |
Suspension/Mounting: |
Spring-loaded clips for ceiling < 1.0 in (25 mm) thick |
THD+N: |
< 1% at 1 kHz (1 Pa/94 dB SPL) |
Technology: |
Omnidirectional electret condenser |
Unit of Sale: |
Each |
