Description
The Antari SPLIT6 is a compact indoor DMX distribution unit that takes one 5-pin DMX feed and provides a thru connection plus six isolated outputs. It is built for stage, touring, and installed lighting systems that need dependable signal distribution without filling a full rack space.
Features
- 1 x 5-pin XLR DMX input
- 1 x 5-pin XLR DMX thru connection
- 6 x 5-pin XLR DMX splitter outputs
- 100% isolation between inputs and outputs
- Signal and power LED indication for each output
- Built-in DMX terminator
- Wall or truss mounting
- IP20 indoor-rated housing
- 6W power consumption
Why We Like This
It gives you six clean DMX branches from one feed in a small, mountable box. The isolated outputs and per-output indicators are especially useful when troubleshooting a larger lighting rig.
FAQs
Q: How many DMX outputs does the SPLIT6 provide?
A: It provides six 5-pin XLR splitter outputs, plus a separate 5-pin XLR thru connection.
Q: Are the DMX connections isolated?
A: Yes. The manufacturer specifies 100% isolation for all inputs and outputs.
Q: Can the SPLIT6 be mounted on truss?
A: Yes. It is designed for either wall or truss mounting.
Q: Is the SPLIT6 weather rated?
A: No. It carries an IP20 rating and is intended for indoor use.
Based in Chicago, IL, Gear Club Direct supports musicians, integrators, and creators every day with reliable gear and expert service.
Tech Specs
Product Type: |
Indoor 6-Way DMX Splitter |
DMX Input: |
1 x 5-pin XLR |
DMX Thru: |
1 x 5-pin XLR |
DMX Outputs: |
6 x 5-pin XLR |
Isolation: |
100% for all inputs and outputs |
Indicators: |
Signal and Power LED for each output |
Power Connector: |
PowerCON input |
Power Input: |
240V |
Power Consumption: |
6W |
IP Rating: |
IP20 |
Mounting: |
Wall or truss mounting |
Dimensions: |
242 x 140 x 55 mm |
