Description
The Event Lighting F160QW is a professional quad-color LED Fresnel spotlight featuring four 40W RGBW (Warm White) LEDs, manual zoom, high CRI output, and silent fanless cooling. Designed for theaters, broadcast studios, houses of worship, galleries, and live productions, it delivers smooth color mixing, adjustable beam control, and flicker-free performance in a compact fixture.
Photometrics
- Light Source: 4 x 40W 4in1 RGBW(Warm White) LED
- CRI: Warm white - 80, but it can be up to 95 mixing with RGB（low level)
- Beam Angle: 15°~55°
- Field Angle: 25°~65°
- Output: 3,000 lux @3M at 15°, 820 lux @3M at 55°
- Lens: 80mm Planconvex lens
- PWM: 24,000 Hz
- LED Lifespan: 50,000 hours
Effects
- Dimming: 0~100%, 16-bit
- Strobe: 1~25Hz
- Zoom: Manual, 15°~55°
- Barn Door: Included
- Gel Clip: Included
Power
- Power Supply: 100~240V AC, 50/60Hz, 160W
- Power Connection: True1 in/out
Control
- Operational Modes: Manual, Master / Slave & DMX, WDMX (optional), RDM
- Display: 4-button LCD control panel
- Control Protocol: DMX512
- DMX Channel Mode: 1 / 2 / 3 / 4 / 6 / 10 / 11 / User
- Control Interface: 5-pin XLR in/out
Housing
- Housing Materials: Die- cast Aluminum Housing
- Housing Finishing: Matte Black
- Cooling: Fanless Cooling with Temperature Protection
- Dimensions: 217.5 x 190.5 x 200mm / 8.6" x 7.5" x 7.9"
- Net Weight: 3.4 kg / 7.5 lbs
Why We Like This
The F160QW delivers the classic soft Fresnel beam with modern RGBW LED technology, silent operation, excellent color rendering, and flexible manual zoom, making it a superb choice for theaters, broadcast studios, churches, and professional stage productions.
FAQs
Q: Is the F160QW suitable for broadcast and video production?
Yes. The 24,000Hz PWM frequency provides flicker-free performance for cameras and live streaming.
Q: Does the fixture include barn doors?
Yes. Both barn doors and a gel clip are included for enhanced beam shaping and lighting control.
Q: Is the cooling fan silent?
The fixture uses a completely fanless cooling system with temperature protection, making it ideal for quiet environments.
Q: Does it support wireless DMX?
Yes. Optional WDMX support is available in addition to DMX512 and RDM control.
Based in Chicago, IL, Gear Club Direct supplies professional Fresnel lighting, theatrical fixtures, broadcast lighting, and stage production equipment for theaters, houses of worship, studios, event venues, and live entertainment professionals.
