Description
The Antari DELUGE M120WFX is a compact IP65 moving head zoom wash built around a 120W RGBL light engine and a 140mm Fresnel lens. A surrounding ring of 48 x 1W RGBWW Aura LEDs adds pixel-style effects, while the motorized 3.8° to 38° zoom covers everything from a tight beam to a broad wash.
Features
- 1 x 120W RGBL main LED light engine
- 48 x 1W RGBWW Aura LEDs for surrounding visual and pixel effects
- Motorized 3.8° to 38° zoom with 140mm Fresnel lens
- 93,750 lux output at 2m with 3.8° zoom
- IP65-rated housing for indoor and outdoor production use
- DMX, ArtNet, and sACN control support
- 18 / 20 / 23 / 41 / 225-channel DMX modes
- 540° pan and 230° tilt movement
- 16-bit 0-100% dimming with flicker-free operation
- 5-pin DMX and RJ45 data connections
- IP65 True1 power input and output
Why We Like This
The DELUGE M120WFX gives you two looks from one compact fixture: a smooth Fresnel wash from the main RGBL engine and an Aura ring for more animated eye-candy effects. The wide motorized zoom and IP65 housing also make it useful for both indoor shows and outdoor stages.
FAQs
Q: Is the DELUGE M120WFX suitable for outdoor use?
A: Yes. The fixture has an IP65-rated housing designed for outdoor as well as indoor production use.
Q: What is the zoom range?
A: The motorized zoom adjusts from 3.8° to 38°, allowing the fixture to move between tighter and wider wash coverage.
Q: What control protocols does it support?
A: It supports standard DMX as well as ArtNet and sACN network control.
Q: What are the Aura LEDs used for?
A: The 48 RGBWW Aura LEDs surround the main Fresnel wash and can create additional visual and pixel-style effects.
Based in Chicago, IL, Gear Club Direct supports musicians, integrators, and creators every day with reliable gear and expert service.
Tech Specs
Product Type: |
IP65 Moving Head Zoom Wash |
Main Light Source: |
1 x 120W RGBL LED |
Aura Light Source: |
48 x 1W RGBWW LEDs |
Beam Angle: |
3.8°-38° |
Zoom: |
Motorized 3.8°-38° |
Lens: |
140mm Fresnel |
Output: |
93,750 lux @ 2m (3.8° zoom) |
LED Lifespan: |
50,000 hours |
Dimming: |
0-100%, 16-bit |
Strobe: |
Yes |
Pan: |
540° |
Tilt: |
230° |
Control Modes: |
DMX, Auto, Sound Active, Master/Slave |
Control Protocols: |
DMX, ArtNet, sACN |
DMX Channels: |
18 / 20 / 23 / 41 / 225 |
Control Interface: |
5-pin DMX in/out, RJ45 in/out |
Display: |
LCD control panel |
Input Voltage: |
100-240V AC, 50/60 Hz |
Maximum Power Consumption: |
180W |
Power Connection: |
IP65 True1 in/out |
Housing: |
ABS and steel, matte black finish |
IP Rating: |
IP65 |
Dimensions: |
11.1 x 9.8 x 14.4 in (282 x 250 x 365 mm) |
Net Weight: |
15.4 lb (7 kg) |
