Description

The Solecis SDX is a family of small digital AV switchers. The 4x1 4K HDMI Solecis Digital Switcher is a 4K and Ultra High Definition (UHD) capable solution that provides four user connection points and includes simplified local control which routes the selected signal to both a DXLink and HDMI output. This provides a simple, low cost solution that combines a DXLink Transmitter and digital switcher into a single small form factor device that is commonly used at a table.

Features

Solecis 4x1 4K HDMI Digital Switcher with DXLink Output
4K and Ultra High Definition (UHD) Support - Experience high-quality video resolution for 4K devices
Multiple Video, Audio and Ethernet Connections - All the connections you need at the conference table including audio, video, control and network access
Switch Inputs Without the Need for a Central Controller - Provides low cost solution for huddle spaces and classrooms
Works with HydraPort Single Button or Keypad Modules - Provides an elegant installation in a table or lectern
Built-in Support for AxLink Keypads - Forwards keypad commands to a central controller over Ethernet eliminating the need for a separate AxLink cable run
FG Numbers: FG1010-314

Why We Like This

We like how the SDX-414-DX brings professional signal routing into a focused AMX platform, helping integrators build cleaner systems with fewer workarounds.

FAQs

Q: What does the SDX-414-DX do?
A: The SDX-414-DX is an AMX digital av switcher for professional AV and control-system installations.

Q: Where is the SDX-414-DX typically used?
A: It is intended for installed AV environments such as conference rooms, classrooms, collaboration spaces, control rooms, and other integration projects where its listed function is required.

Q: Is the SDX-414-DX currently available?
A: The source lists the SDX-414-DX as limited availability; confirm current availability before ordering.

Q: What is the ordering number for the SDX-414-DX?
A: The listed number is FG1010-314.

Based in Chicago, IL, Gear Club Direct supports musicians, integrators, and creators every day with reliable gear and expert service.

Tech Specs

4K Resolution Support:	3840 x 2160p @ 24/25/30 Hz, 4096 x 2160p @ 24/25/30 Hz, 3840 x 2160p @ 60 Hz, 4:2:0, 4096 x 2160p @ 60 Hz, 4:2:0
Audio Format Support:	Dolby TrueHD, Dolby Digital, DTS-HD Master Audio, DTS, 2 CH through 8 CH L-PCM; Dolby Digital and DTS support up to 48kHz, 5.1 channels
Audio Inputs:	(4) HDMI connections support digital audio
Audio Video Switching:	4x1 (dual) audio/video switching, any of 4 inputs can be routed to the HDMI and DXLink output simultaneously
AxLink Keypad Port:	(1), 4-pin 3.5 mm captive-wire connector, provides data and power to up to 2 external AxLink Keypads
Brand:	AMX
Compatible AMX Enova DVX/DGX and DXLink Products:	Enova DGX 800/1600/3200/6400 Digital Media Switchers with DGX-I-DXL-4K DGX DXLink Twisted Pair 4K Input Board installed DX-RX-4K, DXLink 4K HDMI Receiver Module as a point-to-point solution
Dimensions:	1 11/16" x 8 3/4" x 6 7/8" (42.16 mm x 222.25 mm x 175.92 mm)
Ethernet Connections:	(2) RJ-45, 10/100 Port provides TCP/IP communication; an Auto MDI/MDI-X enabled port which allows use of either straight-through or crossover Ethernet cables. The Ethernet Port LEDs show communication activity, connection status, speeds and mode info
FG Numbers:	FG1010-314
Model:	SDX-414-DX
MyTurn Source Selection:	Use in conjunction with MyTurn Source Selector Buttons installed onto HDMI/VGA cables at a source device and a MyTurn Source Selector Receiver that triggers switching. A HydraPort 2-Button Keypad Module can trigger a switch for multiple connections.
Product Status:	Limited Availability
Product Type:	Digital AV Switcher
SKU:	FG1010-314
Video Inputs:	(4) HDMI; supports HDMI/HDCP
Video Outputs:	(1) HDMI; supports HDMI/HDCP, (1) DXLink; supports digital video, audio, Ethernet, and bi-directional control
