AMX

AMX PSR5.4 12 VDC 5.4 A Power Supply

$220.00
SKU:
FG423-48
UPC:
718878022917
Width:
2.00 (in)
Height:
1.25 (in)
Depth:
4.50 (in)
Shipping:
Free Shipping
Current Stock:

Description

The AMX PSR5.4 is a 12 VDC, 5.4 A power supply designed for compatible AMX installation hardware. It includes a 3.5 mm Phoenix-style connector with retention screws and provides regulated DC power with overload, over-voltage, over-current, short-circuit, transient, and thermal protection.

Features

  • 12 VDC power supply for compatible AMX equipment
  • Provides up to 5.4 A maximum output current
  • Includes 3.5 mm Phoenix-style connector with retention screws
  • Universal 100-240 VAC input voltage support
  • 47-63 Hz input frequency range
  • Switching regulated and overload protected design
  • Protection against over-voltage, over-current, short-circuit, transient, and thermal conditions
  • Green LED power indicator shows DC output presence
  • Molded black matte plastic enclosure
  • Includes IEC power cord terminated with grounded Edison plug

Why We Like This

The PSR5.4 is a practical replacement or system power supply for AMX installations that require stable 12 VDC power and a secure captive-wire connection. Its protection features and wide AC input range make it well suited for professional AV environments.

FAQs

Q: What output voltage does the AMX PSR5.4 provide?
A: The PSR5.4 provides 12 VDC output.

Q: What is the maximum output current of the PSR5.4?
A: The power supply provides up to 5.4 A maximum output current.

Q: What connector is included with the AMX PSR5.4?
A: It includes a mini 2-pin captive-wire connector, also described as a 3.5 mm Phoenix connector with retention screws.

Q: What protection features are built into the PSR5.4?
A: It includes over-voltage, over-current, short-circuit, transient, thermal, switching-regulated, and overload protection.

Based in Chicago, IL, Gear Club Direct supports musicians, integrators, and creators every day with reliable gear and expert service.

Tech Specs

Brand:
AMX
Model:
PSR5.4
FG Number:
FG423-48
Product Type:
12 VDC 5.4 A Power Supply
Input Voltage:
100-240 +10% VAC
Input Frequency:
47-63 Hz
Input Current:
<2 A max at 100 VAC and full load; <1 A max at 230 VAC and full load
Output Voltage:
12 VDC
Output Current:
5.4 A max
Ripple and Noise:
200 mV peak-to-peak at full load
Protection:
Over-voltage, over-current, short-circuit, transient, thermal, switching regulated, and overload protected
Power Indicator:
Green LED indicates the presence of DC on the output
Connectors:
Mini 2-pin captive-wire connector (3.5 mm)
Power Cable:
50 mm IEC power cord terminated with a grounded Edison plug for AC input
Enclosure Material:
Molded black matte plastic
Operating Temperature:
32 degrees F to 104 degrees F (0 degrees C to 40 degrees C)
Certification:
UL US listed Class I Power Supply, CSA approved, CE approved, AS/NZS 60950-1 Australia/New Zealand, BSMI Taiwan, CCC China, CU Russia, UL Energy Verified, KC Korea, TUV GS Germany
