Description
Utilizing JPEG2000 encoding, the N2400 Series encoders and decoders are able to deliver cinema quality video with sub-frame latency. These products support 4K60 4:4:4, HDMI 2.0, HDCP 2.2, and HDR allowing end users to realize the full potential of their source and display devices. To preserve the security of the network, N2400 supports enterprise security features such as Active Directory integration and 802.1X support. Operating on standard 1 Gbps networks and requiring only POE+ power, the N2400 encoders and decoders provide the most scalable 4K60 4:4:4 solution.
Features
- JPEG 2000 4K60 4:4:4 & HDR Video Over IP Encoder Card with POE+, KVM, & AES-67
- Supports 4K60 video workflows
- Supports 4:4:4 video processing
- Supports HDR content
- Supports KVM applications
- Supports Power over Ethernet connectivity
- Uses JPEG 2000 video compression
- Ports: +12V 3A DC power input, (P0) Gigabit Ethernet port with POE+ support, (P1) 1G SFP port, (IR) 2-pin 3.5mm screw terminal, (RS232) 3-pin 3.5mm screw terminal, (Audio) 5-pin 3.5mm screw terminal, HDMI video input, DB15 analog video input, HDMI video output, USB Mini B control input (front panel), 2 USB Type A control inputs (front panel), (IR IN) 3-pin 3.5mm screw terminal (front panel)
Why We Like This
This AMX networked AV product supports scalable IP-based video distribution, helping integrators build organized, high-performance signal transport systems.
FAQs
Q: What is the AMX NMX-ENC-N2412A-C Encoder Card?
A: The AMX NMX-ENC-N2412A-C Encoder Card is jpeg 2000 4k60 4:4:4 & hdr video over ip encoder card with poe+, kvm, & aes-67.
Q: What AMX FG number is listed for the NMX-ENC-N2412A-C Encoder Card?
A: FGN2412A-CD
Q: What type of product is the AMX NMX-ENC-N2412A-C Encoder Card?
A: JPEG 2000 4K60 4:4:4 & HDR Video Over IP Encoder Card with POE+, KVM, & AES-67
Q: What is the availability status of the AMX NMX-ENC-N2412A-C Encoder Card?
A: Discontinued
Based in Chicago, IL, Gear Club Direct supports musicians, integrators, and creators every day with reliable gear and expert service.
Tech Specs
Audio Inputs: |
Embedded audio on HDMI (DVI-D through adapter) or Analog Stereo (Balanced or Unbalanced) |
Audio Outputs: |
Network PCM and AES67 audio over Ethernet via RJ45 |
Brand: |
AMX |
Environmental: |
Temperature - 32° to 104°F (0° to 40°C)Humidity - 10% to 90% RH (non-condensing)Heat Dissipation - Up to ~102 BTU/hr |
FG Numbers: |
FGN2412A-CD |
Manufacturer: |
AMX |
Model: |
NMX-ENC-N2412A-C Encoder Card |
Ports: |
+12V 3A DC power input, (P0) Gigabit Ethernet port with POE+ support, (P1) 1G SFP port, (IR) 2-pin 3.5mm screw terminal, (RS232) 3-pin 3.5mm screw terminal, (Audio) 5-pin 3.5mm screw terminal, HDMI video input, DB15 analog video input, HDMI video out |
Product Status: |
Discontinued |
Product Type: |
JPEG 2000 4K60 4:4:4 & HDR Video Over IP Encoder Card with POE+, KVM, & AES-67 |
Regulatory Compliance: |
FCC, CE, UL and NTRL |
Video Inputs: |
HDMI, DVI-D, Dual-Mode DisplayPort (DP++), RGB/YUV DVI-D and Dual-Mode DisplayPort (DP++) are supported through a passive adapter |
Video Outputs: |
Network video over Ethernet via RJ45 port or fiber via 1G SFP port |
Video Resolution Support: |
HDMI and DVI (Progressive) Pixel clock between 27 MHz - 600 MHz Minimum resolution of 720x480p Maximum horizontal resolution of 4096 or a vertical resolution of 2160 Common acceptable resolutions include: 720x480@60Hz (480p60), 1024x768p60, 1280x720@ |
