Description
The DGX-I-HDMI-4K60 is a 4K60 4:4:4 input board for the Enova DGX 800, Enova DGX 1600, Enova DGX 3200, and Enova DGX 6400. The board is Ultra High Definition (UHD) capable and HDCP 2.2 compliant, with support for full 4K60 4:4:4 video and High Dynamic Range (HDR) for optimum image quality and full bandwidth, pixel-for-pixel image reproduction without compression or chroma subsampling. It has four connections and supports HDMI with embedded audio, DisplayPort++ or DVI signals.
Features
- Enova DGX 4K60 4:4:4 HDMI Input Board
- 4K60 4:4:4 Support - Experience pixel-for-pixel video reproduction with full bandwidth 4K60 images with full 4:4:4 color space
- HDCP 2.2 Support with InstaGate Pro Technology - Support the latest entertainment devices and enjoy hassle-free matrix switching to all compliant displays.
- High Dynamic Range (HDR) - Dramatically improve the viewing experience with broader color range for improved clarity
- Hot Swappable - Easily add or replace I/O boards at any time after deployment - the system automatically recognizes the new configuration and activates the boards
- Surround Sound Support - Pass through high definition surround sound including Dolby Atmos, Dolby TrueHD, Dolby Digital, Dolby Digital Plus, DTS-HD Master Audio, DTS, and 2-channel through 8-channel L-PCM
- Connectors: 4 HDMI Type A Female Ports
Why We Like This
We like the DGX-I-HDMI-4K60 for extending or adapting AV signals with hardware designed specifically for integrated AMX systems.
FAQs
Q: What does the DGX-I-HDMI-4K60 do?
A: The DGX-I-HDMI-4K60 is an AMX matrix switcher input board for professional AV and control-system installations.
Q: Where is the DGX-I-HDMI-4K60 typically used?
A: It is intended for installed AV environments such as conference rooms, classrooms, collaboration spaces, control rooms, and other integration projects where its listed function is required.
Q: What is the ordering number for the DGX-I-HDMI-4K60?
A: The listed number is FG1061-542.
Based in Chicago, IL, Gear Club Direct supports musicians, integrators, and creators every day with reliable gear and expert service.
Tech Specs
AIE Board Support: |
Yes, extraction of 2 CH L-PCM selectable by channel |
Audio Format Support: |
Dolby TrueHD, Dolby Digital, DTS-HD Master Audio, DTS, 2 CH through 8 CH L-PCM, Dolby Digital and DTS support up to 48 kHz, 5.1 channels |
Audio Switching Board Support: |
Supports break-away audio switching of 2 CH L-PCM for all channels Supports down-mix from one input channel of Dolby True-HD, Dolby Digital, DTS-HD, DTS, or 2 to 8 channel L-PCM Note: Down-mix supported on 4K video inputs withpixel clocks up to 297 M |
Brand: |
AMX |
Compatible Formats: |
HDMI, HDMI 2.x, HDCP, HDCP 2.2, DVI |
Connectors: |
4 HDMI Type A Female Ports |
FG Numbers: |
FG1061-542 |
JITC Status: |
Approved - 04/2023 |
Maximum Resolution Support: |
3840x2160p@24/25/30/60 Hz @ 4:4:4, 4096x2160p@24/25/30/60 Hz @ 4:4:4 (when used with compatible Enova DGX 100 Series enclosures) |
Model: |
DGX-I-HDMI-4K60 |
Product Type: |
Matrix Switcher Input Board |
SKU: |
FG1061-542 |
Signal Type Support: |
HDMI, HDMI 2.x, DVI-D (Single Link With HDMI Cable Adapter), DisplayPort ++ (Input Only, With HDMI Cable Adapter) |
