Description
The Allen & Heath IP8 is a compact and portable remote controller for AHM matrix processors or dLive and Avantis mixing systems—ideal for many install and live sound applications. It features 8 motorized faders, 8 LCD displays, 23 backlit softkeys and a dimmable preset control for all displays. The faders are fully assignable, configured individually, or part of a vertical strip. There are 6 layers of control accessed via softkeys, allowing control of 48 individual channels.
Fast Ethernet connection is via a locking Neutrik EtherCon connector on the back panel. The IP8 can be connected directly to the dLive Mixrack/Surface, Avantis mixer, or AHM-64 Matrix Processor via standard Cat 5 data infrastructure. Alternatively, the controller can be networked with other controllers, computers, and third-party devices using an Ethernet switch. The IP8 controls and functions are programmed using the AHM System Manager or dLive Director software (Mac/Windows), or via an Avantis mixer or dLive Surface. The unit is powered by an external 12 VDC PSU or over Ethernet (PoE+).
Features
- For for AHM matrix processors or dLive and Avantis mixing systems
- Uses standard TCP/IP network connections
- 8 motorized faders
- 23 backlit softkeys
- 8 LCD displays
- 6 x layers of control
- PoE+ or external 12 VDC PSU (included)
- Use freestanding or mount in a plinth, podium, or furniture
- Optional wall-mount bracket (IP8-MOUNT)
Surfaceless Mixing
- Teamed up with a dLive MixRack and a laptop running Director software, IP8 is ideal for adding hands-on control to an ultracompact dLive setup, such as a monitor rig for fly-in dates.
Surface Extender Application
- The sound engineer can make use of all fader strips on a dLive Surface or Avantis mixer to control input channels, and to set up a "sidecar" IP8 to control master levels or FX sends/returns.
Personal Monitoring Application
- The IP8 can be configured to control the Send levels and assignments of multiple channels to a specific mix on the dLive, for example for wireless IEM use, giving musicians the freedom to control their own monitor sound.
Installation Application
- The installer or system integrator can configure the IP8 to provide the degree of control needed by the day-to-day operator, for example, the levels of microphones and music sources in a room.
Tech Specs
Compatibility: |
dLive, Avantis, AHM-64 |
Network: |
Fast Ethernet 100 MB/s |
Power: |
Power Adapter (Included): +12 VDC, 2.5 A PoE+: 802.3at (25.5 W at Source) |
Maximum Power Consumption: |
25 W |
Dimensions (W x D x H): |
11.4 x 8 x 2.4" |
Weight: |
5.5 lb |
