Description
The Crown CT 475 is a convection-cooled four-channel DriveCore amplifier delivering 75W per channel for installed sound. Its efficient 1U design, flexible input routing, universal power supply, and life-safety-oriented monitoring features make it well suited to quiet commercial environments and distributed audio systems.
Features
- Flexible Input Routing
- Convection Cooled
- Universal Power Supply
- Integrated Life-Safety Features
- Up to 8X125W in 1U chassis with no fan
- DriveCore™ technology provides >90% efficiency with no compromise in performance
- Patented Feedback and Protection Circuits
- Amplifier is stable for 2 – 16 Ohm Loads
- XFMR 4/8 needed for 70V/100V Applications
Why We Like This
It gives integrators flexible speaker-load support and dependable Crown amplification in a rack-friendly platform that is straightforward to configure and maintain.
FAQs
Q: How much power does the Crown CT 475 deliver?
A: It is a 4-channel amplifier rated at 75W per channel for the primary published load condition.
Q: What speaker systems can the CT 475 drive?
A: It is designed for low-impedance speaker systems; exact supported loads and bridge modes are listed in the technical specifications.
Q: Does the CT 475 include DSP or network control?
A: No network audio is built in. The CT Series focuses on efficient, fanless multichannel amplification and can be paired with external system processing.
Based in Chicago, IL, Gear Club Direct supports musicians, integrators, and creators every day with reliable gear and expert service.
Tech Specs
Brand: |
Crown |
Channels: |
4 |
Common Mode Rejection (20 Hz to 1 kHz): |
> 55 dB, typically > 70 dB |
Country of Origin: |
CN |
Crosstalk (below rated power) 20 Hz to 1 kHz: |
> 70 dB |
DC Offset: |
+/- 20mV |
DIM H (in.): |
5 |
DIM L (in.): |
21.5 |
DIM W (in.): |
21 |
Dimensions: |
1.75" x 19" x 15.19" |
Frequency Response (at 1W, 4/8 ohms): |
+/- 0.5 dB |
IEC Power Connector: |
15A |
Idle Power Consumption (Standard Mode): |
15.0W |
Intermodulation Distortion (from 0 dB down to -30 dB): |
< 0.05% |
Model: |
CT 475 |
Product Type: |
Four-Channel DriveCore Power Amplifier |
Rated Power Output (all channels driven): |
75W per CH @ 4 ohms, 75W per CH @ 8 ohms |
SKU: |
NCT475A-U-US |
Sensitivity: |
1.4 V |
Signal to Noise Ratio (below rated power 20 Hz to 20 kHz, A-Weighted): |
110 dB |
TAA Compliance: |
Non Compliant |
THD (full rated power, 20 Hz - 20 kHz): |
< 0.05% |
UPC: |
871015004754 |
Voltage Gain: |
25 dB |
Weight (lb.): |
11 |
